Installation and technical manual
Electric Combination Heaters TT-KS mobile /castors
TT-KS S
TT-KS N
TT-KS H
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.
BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE
Edition:12/17
Id_Nr. 911 360 950
Eco-Design Directive 2015/1188:
This product is only suitable for well-
insulated rooms or for occasional use
.
2
3
Feet using:
GB
Advertisement
Related Manuals for Technotherm TT-KS 500 S
Summary of Contents for Technotherm TT-KS 500 S
- Page 1 Installation and technical manual Electric Combination Heaters TT-KS mobile /castors Eco-Design Directive 2015/1188: Feet using: This product is only suitable for well- insulated rooms or for occasional use TT-KS S TT-KS N TT-KS H THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. BE SURE TO OBSERVE ALL LABELS AND WARNINGS ON THE APPLIANCE Edition:12/17 Id_Nr.
- Page 2 Manual TT-KS 1. For your safety • This appliance is intended for normal household use and not for use for vehicles or on board ships or aircrafts. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction...
- Page 3 Manual TT-KS • CAUTION — Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present. • Make sure that your supply rating corresponds to what specified on the rating plate: 230V~, 50Hz.
- Page 4 Manual TT-KS Electrical Connections: The wires in the mains leads are colored in accordance with the following code: GREEN & YELLOW: EARTH BLUE: NEUTRAL BROWN: LIVE WARNING – THIS APPLIANCE MUST BE EARTHED The installation of this appliance should be carried out by a competent electrician in accordance with I.E.E.
-
Page 5: General Information
These models can controlled by our digital transmitter TBF or TPF. All TECHNOTHERM radiators are manufactured to the highest safety and quality Standards. Each radiator is CE Marked and carries all the necessary European Approvals. -
Page 6: Electrical Connection
Loosen the gland and pull the sensor down by 50 - 70 millimeters, then re-tighten the gland. This enables the radiator to gauge the room’s temperature more accurately Electrical connection All TECHNOTHERM TT-KS radiators come with a standard UK 3 pin plug that can be directly connected to an electrical socket. Alternatively the mains cable can be... - Page 7 Manual TT-KS 3.3 Radio frequency – wired versions model E4 The regulation of the desired room temperature implements a built-in temperature control device. position 0 : OFF position 1 : approx. 5°C (frost protection) position 4 : approx. 20°C position 6 : approx 30°C An illuminated display indicates the heating process of the radiator.
- Page 8 Manual TT-KS 4.0 Operating safety This appliance complies with the European Standards EN 60 335-1, EN 60 335-2-61, EN 61000-3-2, EN 61000-3-3, EN 55014 and EN55104 for Safety & Electromagnetic Compatibility. These standards cover the requirement of the EMC Directives 89/336 & 73/23 RADIATOR POSITIONING - A minimum clearance of 150mm to the front of the radiator is essential for safety, however to enable the radiator to attain its maximum performance ensure that any furniture or other obstruction is not placed closer than 250mm.
- Page 9 Manual TT-KS No attempt should be made to move the radiator without first seeking specialist advice. If you are not happy that the radiator has been securely fixed, please inform your installer. DO NOT SIT OR STAND ON THE RADIATOR. DO NOT SPILL LIQUIDS ONTO THE APPLIANCE.
- Page 10 Interface (Art.Nr.750 000 640) or DSM-Thermostat with the DSM-Interface (Art.No.:911 950 101) • from Technotherm meet the following requirements and therefore the ErP Directive: electronic room temperature control plus week timer (RF/DSM) • room temperature control, with open window detection (DSM) •...
- Page 11 Manual TT-KS Model: TT-KS S DSM / TT-KS N DSM / TT-KS H DSM (additional DSM interface necessary) Item Value Item Symbol Value Value Heat output Type of heat input, for electric storage local space heaters only (select one) Nominal heat manual heat charge control, with P nom 1000...
- Page 12 TECTECHNOTHERM Service: Fon: +49 (0)911-93 78 32 10 Lucht LHZ Elektroheizung GmbH & Co. KG Reinhard-Schmidt-Str. 1 D-09217 Burgstädt Fon: +49 (0) 3724 66869 0 Fax: +49 (0) 3724 66869 20 E-mail: info@technotherm.de web: www.technotherm.de edition: 12/17...
