Before beginning, disconnect the negative (-) terminal of the
battery prior to working on the positive (+) terminal to prevent
a short to ground. This is important, unless you want to spend
the rest of your life with a nickname like "Sparky," or "Smokey."
Reconnect the negative terminal only after all connections have
been made.
Factory Ground wire may
need to be replaced if it is
frayed or broken.
Run signal cables (RCAs)
and remote turn-on lead
down the opposite side of
the vehicle of the power
wire to avoid radiated noise.
Avoid sharp edges that
could chafe through the
insulation.
W a r n i n g !
Fuse must be installed within 18" of battery
WIRING
eject
1 2 3 4
Trk 1
5 6 7 8
BASS TREBLE
VOLUME BALANCE TRACK PPI MAR KET ING DPT
LEFT RIGHT FOWARD REVERSE
5
Positive
Battery
Terminal
Fuse must be
installed within
18" of battery
Drill a hole in the firewall
and use a rubber grommet
to keep wire from shorting.
Run the cables under the
carpet near the side of the
vehicle. Be careful not to
drill or screw into the wires
when you replace the trim.
For systems over 300 watts,
add a ground cable from the
amp to the battery
(see page 6).
Firmly attach Amp
Ground Wire to solid
metal (see page 6).
