Features & Specifications - Precision Power PowerClass PC4200 Owner's Manual

Your new amplifier incorporates some or all of the following features:
Adaptive MOSFET Switching Power Supply
Fully Complementary Darlington Output Stage
AP III Protection Circuitry (PC4200, PC4400, PC6800)
AM IV Protection Circuitry (PC4800)
QBASS ™ Bass Boost (PC4200, PC4400)
QBASS PLUS ™ (PC4800, PC6600)
QBASS REMOTE ™ Compatible (PC4800, PC6600)
PowerLock Speaker and Power Wire Connectors
Detented, Variable 3-way Internal Crossover
Non-Fading Sub Channel
Balanced Differential Input Stage
High Voltage Input Capability with Input Attenuation Switch
Gold Plated RCA Input and Output Connectors
Mixed Mono/Stereo Operation
3 Year Warranty when installed by an Authorized PrecisionPower Dealer
Completely Designed And Handcrafted In The USA
S p e c i f i c a t i o n s
Power Bandwidth:
Total Harmonic Distortion:
Input Topology:
Input Sensitivity:
Input Impedance:
Load Impedance (stereo)
Load Impedance (bridge)
Supply Voltage
Damping Factor
Slew Rate
Idle Current:
C o n t i n u o u s O u t p u t P o w e r
PC4200
25 WRMS x 4 @ 4 per channel
50 WRMS x 4 @ 2 per channel
100 WRMS x 2 @ 4 bridged
PC4400
50 WRMS x 4 @ 4 per channel
100 WRMS x 4 @ 2 per channel
200 WRMS x 2 @ 4 bridged
FEATURES / SPECIFICATIONS
4.5 Hz - 100 kHz
0.02 %
Differential
150mv - 12 volts RMS
10k Ohms
2 - 8 Ohms
4 - 8 Ohms
11 - 15 volts
>500
>50 V/ S
PC4200 / PC4400 - 1.5 Amps
PC4800 - 3.0 Amps
PC6600 - 2.0 Amps
PC6600
50 WRMS x 6 @ 4 per channel
100 WRMS x 6 @ 2
200 WRMS x 3 @ 4 bridged
PC4800
100 WRMS x 4 @ 4
200 WRMS x 4 @ 2
400 WRMS x 2 @ 4
1
per channel
per channel
per channel
bridged
