Q BASS
™ and
QBASS ™ (PC 4200, PC4400, and PC 6600)
Up to 12dB of Boost centered at 40Hz, with a Q-Factor of 2.
QBASS PLUS ™ (PC 4800)
Up to 18dB of Boost with selectable center frequency at 30Hz, 36Hz,
44Hz or 60Hz. Selectable Q of 2 or 4. Optional remote mounted
Boost Control.
Optional QBASS REMOTE
This boost control can be mounted
in the dash and will supersede the
boost control on the amplifier endplate.
Optional QPORT
allows one QBASS REMOTE
operate multiple amplifiers. Each
™
QPORT
has outputs for four amplifiers
as well as another QPORT
expansion. See your authorized PrecisionPower
dealer for more information!
C r o s s o v e r S p e c i f i c a t i o n s
PC4200 / PC4400
Front - 12dB/Octave, Detented High Pass 20-5kHz
Rear - 12dB/Octave, Selectable Detented High or Low Pass 20-5kHz
RCA Out-Summed Mono 24dB/Octave, Linkwitz-Riley Low Pass, 90Hz
QBASS ™ on Rear Channel
PC4800
Front - 12dB/Octave, Detented High Pass 20-5kHz
Rear - Choice of 12dB/Octave Detented High Pass 20-5kHz, or
Summed Mono 24dB/Octave, Linkwitz-Riley Detented Low Pass 44-315Hz
RCA Outputs will be the opposite of your Rear Crossover choice.
QBASS PLUS ™ on Rear Channel
PC6600
Front - 12dB/Octave, Detented High Pass 20-5kHz
Rear - 12dB/Octave, Detented High Pass 20-5kHz
Sub-Summed Stereo 24dB/Octave, Linkwitz-Riley Low Pass at 90Hz
QBASS PLUS ™ on Sub Channel.

Dimensions

PC4200
Length - 12.22"
Height - 2.25"
Width - 8.9"
FEATURES / SPECIFICATIONS
Q BASS PLUS
™
(PC 4800)
™
expansion module
™
™
for greater
PC4400
Length - 13.72"
Height - 2.25"
Width - 8.9"
™ Specifications
Q B
to
0
PC6600
Length - 19.72"
Height - 2.25"
Width - 8.9"
2
A S
S
™
+ 1
8
PC4800
Length - 23.72"
Height - 2.25"
Width - 8.9"
