Q BASS
™
For extra BOOM from your system, we've developed the
™
QBASS
to the left of the speaker outputs, and allows you to add up to
12dB of boost centered at 40Hz by rotating the control clockwise.
™
QBASS
Q BASS PLUS
On PC4800 and PC6600 amplifiers, we've taken bass control
to a higher level with QBASS PLUS
(labeled 1 and 2) on the front end of the amplifier allow you
to select one of four frequency centers - 30Hz, 36Hz, 44Hz
and 60Hz. The Q SELECT switch determines the width of
boosted frequencies. A 'Q' of 2 (switch out) will give you a
wide boost while a 'Q' of 4 will boost a narrow range of
frequencies. (See chart below.) On the rear end panel you
will find the QBASS PLUS
for an optional QBASS REMOTE
level control clockwise for up to 18dB of boost at your
selected frequency and Q.
Q BASS PLUS
™
1 2
IN IN
IN OUT
OUT IN
OUT OUT
CAUTION: QBASS
systems with strong subwoofers. 18dB is a lot of bass boost and
could damage full range speakers.
™
Q BASS
and
bass control circuit. The QBASS control is located
Is a standard feature on the PC4200/PC4400 .
™
Settings
Freq.
+18dB
30Hz
+12dB
36Hz
+6dB
44Hz
0dB
60Hz
™
and QBASS PLU
Q BASS REMOTE
™
.
The two QBASS switches
™
level control and the plug-in
™
level control. Adjust the
Q = 4
30Hz
S ™
should only be used in
15
™
QBASS ™
QBASS PLUS
Q = 2
36Hz 44Hz
™
60Hz
