Scope Multimeter
Term / Abbreviation
Threshold
Trace
Trigger
Trigger Slope
VAC
VDC
Vertical Scale
Volt
Voltage
Voltage (inductive) Kick
Waveform
Zero Base Line
Description
The threshold function automatically sets a trigger and
determines a threshold level in the middle of the signal range
(calculated from the Min and Max measurements) to be used
as a reference point to calculate the measurement.
The actual visible line displayed on the scope screen.
A conditional function that initiates if and when a trace is drawn
on the screen.
The slope that a trigger source signal must reach before the
trigger circuit initiates a sweep
Volts Alternating Current
Volts Direct Current
The vertical scale on the grid or (y-axis) represents what is
being measured (voltage, amperage, pressure etc.), and the
unit of measurement it is being measured in.
Unit of electric potential difference.
Electromotive force or potential difference, expressed in volts.
A voltage, many times higher than the applied voltage,
produced by the collapsing magnetic field in a coil when the
current through it is abruptly terminated.
The graphic representation (form) of a signal over time, which
the trace displays on the screen.
Reference setting or 0% level of a graph scale.
100
General Reference
