- Page 1 7590TK15 INSTALLATION AND USE MANUAL AC2594 Rev.02-06/14 Made in Italy...
-
Page 2: Table Of Contents
TABLE OF CONTENTS - PRELIMINARY ADVICE - FUNCTIONS - REMOTE CONTROL OPERATION AND BATTERY REPLACEMENT USER MANUAL - OPERATING INSTRUCTIONS 4.1 - Alarm arming 4.2 - Arming delay, sensor and comfort exclusion, window-up stop 4.3 - Siren sound exclusion when arming 4.4 - Total arming after arming delay 4.5 - Alarm conditions 4.6 - Alarm cycle... -
Page 3: Preliminary Advice
1.0 - PRELIMINARY ADVICE Dear customer The 7590T is a Thatcham alarm unit with dual point immobilization and built- in sensors designed to be used only on vehicles with a negatively grounded 12V battery. The following signs, intended for the installer or the user, indicate particular functions or connections: For the user. -
Page 4: Remote Control Operation And Battery Replacement
3.0 - REMOTE CONTROL OPERATION AND BATTERY REPLACEMENT BUTTON 1: COMPLETE SYSTEM ARMING SYSTEM DISARMING BUTTON 2: SENSOR EXCLUSION PANIC ALARM OR BOOT OPENING The remote control has a low charge battery indicator that gives early warning to avoid manlfunctioning. If t he batteries are low, the LED will start blinking when a button is pressed. -
Page 5: User Manual
USER MANUAL 4.0 - OPERATING INSTRUCTIONS 4.1 ALARM ARMING To arm the alarm press remote control button 1 or touch the electronic key to its receptacle. Arming is confirmed by a quick flash of the turn indicators. The following functions are enabled: Module output (PINK wire, +A). -
Page 6: Alarm Conditions
4.5 - ALARM CONDITIONS Wire tamper ( via the self-powered siren). Ignition attempt. Power drain (if enabled during programming. It can only be used in countries where the use of this sensor is not prohibited). Door tamper. Boot tamper. Bonnet tamper. Motion detection by internal ultrasound volumetric sensor. -
Page 7: Neutral Time Between Alarm Cycles
4.7 - NEUTRAL TIME BETWEEN ALARM CYCLES After the alarm is triggered, but before another alarm cycle starts, there is a 5” interval during which there will be no reaction to alarm events. The LED will be ON steady. Normal flashing will resume at the end of the neutral time. 4.8 - ALARM DISARMING The alarm system can be disarmed by pressing remote control button 1 by touching the electronic key to its receptacle. -
Page 8: Installer Manual
INSTALLER MANUAL 5.0 - ELECTRICAL CONNECTIONS Implement the electrical engine blocks by working on the fuel pump and the starter motor. Connect the alarm positive supply to the vehicle battery or to one of its derivations. Connect the alarm negative supply to the vehicle chassis ( 2 BLACK wires marked M). -
Page 9: Wiring Diagram
6.0 - WIRING DIAGRAM ANTENNA - Do not tamper! ART.7590T ELECTRONIC KEY ALARM SYSTEMS US adjustment 7590 Made in Italy Button 2 Button 1 Black BLACK marked ‘R’ Green Brown Battery YELLOW-BLUE 12 VOLT BLACK marked ‘M’ RED-BLUE YELLOW-GREY EARTH RED-GREY BLACK marked ‘M’... -
Page 10: Programming The Alarm System
7.0 - PROGRAMMING THE ALARM SYSTEM The alarm system has been factory configured but settings can be modified at any time. During programming, proceed as follows: - To enable a function, press textured button ’1’ => LED will flash once - To disable a function, press smooth button ‘2’... -
Page 11: Programmable Functions
8.0 - PROGRAMMABLE FUNCTIONS 8.1 - ACOUSTIC SIGNALS This function allows to permanently exclude all acoustic signals. See the relative paragraph for programming. 8.2 - PANIC ALARM OR BOOT RELEASE If enabled, the PANIC ALARM function allows the user to deliberately activate the optical/acoustic alarm signals by pressing remote control button 2. -
Page 12: Passive Arming
8.5 - PASSIVE ARMING Engine block passive arming, if enabled, automatically activates the double ENGINE LOCK 60 sec. after the engine has been switched OFF or 60 sec. after the alarm has been disabled (if engine is not switched back on). The status LED will flash quickly to confirm activation. -
Page 13: Waste Electrical And Electronic Equipment (Weee)
10.0 - LEARNING NEW CONTROL DEVICES To carry out the operation successfully, make sure the required electrical connections (door /bonnet switch and ignition) have been completed. Storing memory is for 8 devices (remote controls, electronic keys or magnetic contacts (protection devices). If an extra device is added, the LED will start flashing quickly to indicate the memory is full. -
Page 14: Technical Specifications
The warranty will become void if labels are missing or torn, if the installation certificate is not fully compiled or if the enclosed sale document is missing. The warranty is valid exclusively at Authorized Gemini Technologies Service Centers. The manufacturer declines any responsibility for eventual malfunctions of the device or any damage to the vehicle electrical system due to improper installation, use or tampering. - Page 15 R&TTE Declaration of Conformity Doc ref. No. 2010-01 We, the undersigned, Company GEMINI TECHNOLOGIES S.p.A Address, City Via Luigi Galvani 12, 21020 Bodio Lomnago (VA) Country Italy Phone number +39 0332 943211 Fax number +39 0332 948080 Declare under our sole responsibility that the following equipment:...
- Page 16 7 Dudley Court , Jessop Close, Clacton-on-Sea, Essex, CO15 4LY TEL: +44 (0) 1255 434353 Email: sales@avsgemini.com | Web: www.avsgemini.com UK Distributors of the Gemini Alarm Systems...
