IDS800 INSTALLER MANUAL

Figure 4: Programmable Output Configuration

56R
1000R
Output 1
GND

6. Expansion Board

Attached to the keypad bus, in parallel with the keypad, is an optional
expansion board which allows for the following:
Programmable outputs 4 and 5 which function as per the values
programmed into locations 22 - 40 and locations 159 - 166.
Designated keypad buzzer which will function as per the
description in the user manual.
ARM, READY
description in the user manual for keypad LED s.

Figure 5: Expansion Board Connection

Keypad
Keypad connection
on main board
Keypad Buzzer
Power LED
Ready LED
Arm LED
Auxilliary
Outputs
IDS800 INSTALLER MANUAL NO. 700-175-02N ISSUED JUL 2003 VER 1.45
12V
1000R
GND
and POWER LED 's which will function as per the
_
GND
C
CK
D DAT
+ +12V
BZ
+
PR
RD
AM
P4
P5
GD
56R
Output 2
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
ZONE 7
ZONE 8
Expansion
Board
56R
1000R
Output 3
GND
1 2 3
5 6
4
7 8 9
0 #
*
M
F M P
O
D
E
9
