IDS800 INSTALLER MANUAL
13. Programming Instructions
13.1 Introduction
The panel may be programmed either using the keypad or using the
up/download software. Programming the panel by means of the
keypad is explained in the following sections of this manual. For
information on programming the panel using the up/download software
refer to the manual pertaining to the software.
:
NOTE
Before commencing the programming it is advisable to read the
Installer Manual thoroughly
13.2 Location Values
All values within a program location are displayed by the zone
indicators in binary format. The table below indicates how these values
may be read.
Table 2: Value represented by each zone indicator
To read a binary value on the keypad add the values represented by
each illuminated LED . The total value is the number being represented
e.g. Assume the following zone indicators are illuminated: Zone 1,
Zone 3 and Zone 4. The value would be as shown in the table below.
14
IDS800 INSTALLER MANUAL NO. 700-175-02N ISSUED JUL 2003 VER 1.45
Z
o
n
e
1
1
Z
o
n
e
2
2
Z
o
n
e
3
4
Z
o
n
e
4
8
Z
o
n
e
1
1
Z
o
n
e
3
4
Z
o
n
e
4
8
T
t o
l a
1
3
