Step 3: Manual color mix

Adjust the desired DMX values (0 to 255) for the spotlights selected using the R, G, B, W/D faders. The availability
of individual control functions depends on the type of spotlight used and on the assignment to the channel
functions (see step 1).

Step 4: Direct color mix

Alternatively, the controller has a MIX fader which allows fast access to internal RGBW color mixes in a single
movement.

Step 5: Automatic color change programs

Use the RUN MODE to enable automatic mode (AUTO LED lights up). Then use the MAC fader to select one of
the eight programs. The program speed can be set with the SPEED fader.
Program Funvtion
1 RG color fade
2 RB color fade
3 GB color fade
4 RG color change
5 RB color change
6 GB color change

Step 6: Sound control

The internal color change programs can be controlled to the rhythm of music picked up via the integrated
microphone. Use the RUN MODE to enable sound control mode (SOUND LED lights up), then select the desired
program with the MAC fader. You can use the SENSITIVITY fader to match the sensitivity
Step 7: Stroboscope effect
The STROBE button generates a white stroboscope effect. Use the STROBE SPEED fader to adjust the flash rate
from 1 to 20 Hz. If the fader is set to 0, there will be no data output. To deactivate the strobe effect, press the
STROBE button once again.

Step 8: Blackout function

Press the BLACKOUT button to black out all spotlights. The button's LED lights up and all control channels are
set to the output value zero. To switch the spotlights back on again, press the BLACKOUT button once again.
The product is maintenance-free, except for occasional cleaning. You can use a lint-free, slightly dampened cloth
for cleaning. Refer all servicing to qualified personnel.
Power supply:
Power consumption:
Protection class:
Control channels:
Controls:
DMX modes:
Sound-control:
DMX512 output:
Dimensions (L x W x H):
Weight:
Specifications are subject to change without notice due to product improvements.

CLEANING AND MAINTENANCE

TECHNICAL SPECIFICATIONS

9-12V DC, 300 mA connected to 100-240 V AC, 50/60 Hz via included power adapter
<10 W
III
20
R/G/B/W/D, RGBW mix, macros, strobe effect
RGB, RGBD, RGBW, RGBWD, DRGB, DRGBW
via built-in microphone
3-pin XLR connector
115 x 200 x 55 mm
0.8 kg
13 • EN
