LevelOne IGP-0401 User Manual page 5

Removable Terminal Block
Power DIN
Operating Temperature
Operating Humidity
Storage Temperature
MTBF (mean time between failure)
Housing
Case Dimension (W X D X H)
Installation mounting
Certifications
EN55022/24
EN55011
Safety
EMC/EMS
EMI
EN 50155 / EN 60068-2-6
EN 50155 / EN 60068-2-27
EN 50155 / EN 60068-2-32
@24VDC,
Relay in open circuit mode when 2 powers are
connected. in short circuit mode when only one power
supply is connected
Provide 2 Redundant power, Alarm relay contact ,6 Pin
Wire range: 0.34mm^2 to 2.5mm^2
Solid wire (AWG):12-24/14-22
Stranded wire(AWG): 12-24/14-22
Torque:5lb-In/0.5Nm/0.56Nm
Wire Strip length: 7-8mm
For 110VAC/240VAC external power adapter, 4 pin high
current with lock type
-40℃ ~75℃ fully tested.
5% to 95% (Non-condensing)
-40℃ ~85℃
>500,000 hrs. (MIL-HDBK-217F) at 25°C
Rugged Metal, IP30 Protection
142 x 36.2 x 105 mm (L x W x D)
DIN Rail mounting and Wall Mounting
ITE equipment
Industrial, Scientific and Medical (ISM) equipment
IEC EN60950-1
CE, FCC, VCCI
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
Vibration
Shock
Free Fall
5
