IGP-0401
4-Port Gigabit PoE
Industrial Switch
User Manual
Introduction
This IGP-0401 Industrial 4 port Gigabit Ethernet Switch is equipped with two PoE ports. The PSE ports are
critical for your PD environment. They will not only perform your network job, but also provide PSE power
to your PD WiFi or IP CAM applications. This product has been rigorously tested in harsh environment.
These PSE ports can be powered by 48-56 VDC input voltage. The additional Gigabit TX port and Gigabit
SFP port can be easily cascaded to extend your existing networks. With its multi- purpose design, it can
also be Din-Rail or wall-mounted. It is an ideal unit for Mobile Base Station (BTS), IP surveillance, traffic
monitoring and security application in critical environment. It can tolerate -40°C to 75°C in harsh
environment to perform a reliable network.
1
Advertisement
Related Manuals for LevelOne IGP-0401
Summary of Contents for LevelOne IGP-0401
-
Page 1: User Manual
User Manual Introduction This IGP-0401 Industrial 4 port Gigabit Ethernet Switch is equipped with two PoE ports. The PSE ports are critical for your PD environment. They will not only perform your network job, but also provide PSE power to your PD WiFi or IP CAM applications. This product has been rigorously tested in harsh environment. -
Page 2: Installation Package
Installation package This unit can be din-rail mounted or wall-mounted. Din-rail brackets and wall-mounted brackets are included. 6 pin Terminal Block x1 Wall mount bracket x 2 Philips Head Screw x 4 Din Rail Bracket x 1 Power connection This unit provides 6 pin terminal block. The PoE port can be operated from 48-56VDC power source input. Always make sure your input voltage is within this supported voltage range . - Page 4 Specification: IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE Standard IEEE 802.3z 1000Base-X Gigabit Ethernet IEEE802.3x Flow Control and Back Pressure, IEEE802.3af for POE IEEE802.3at for POE+ Switch Architecture Back-plane (Switching Fabric): 8-Gbps Data Processing Store and Forward Flow Control:...
- Page 5 @24VDC, Relay in open circuit mode when 2 powers are connected. in short circuit mode when only one power supply is connected Provide 2 Redundant power, Alarm relay contact ,6 Pin Wire range: 0.34mm^2 to 2.5mm^2 Solid wire (AWG):12-24/14-22 Removable Terminal Block Stranded wire(AWG): 12-24/14-22 Torque:5lb-In/0.5Nm/0.56Nm Wire Strip length: 7-8mm...
-
Page 6: Housing Dimensions
Housing Dimensions...
