Table 4.1 FCS 2.0 Keyword Information
FCS 2.0 Keyword
@PnDivider
@PnGAIN
@PnQ
@PnU
@PnX
@PnZ
@RATIO_DENOMINATOR
@RATIO_NUMERATOR
@RATIODENOMINATORMUX
@RATIONUMERATORMUX
@REDLASERPOWER_END
@REDLASERPOWER_START
@REDLASERSHUTTER
@REDTARGETPOWER
@RESAVEDFILE
@SAMPLEID1
@SAMPLEID2
@SAMPLEID3
@SAMPLEID4
@SETTINGSFILE
@SETTINGSFILEDATETIME
@STOPREASON
TESTFILE
TESTNAME
@TUBENO
@VIOLETLASERPOWER_END
@VIOLETLASERPOWER_START
773232AH
Key value
Specifies the channel of the parameter n prism divider. Only present when the prism
dividers are specified in the software.
Amplifier Gain setting of a sensor associated with parameter n.
Sensor name for parameter n, from the Cytometer Control screen.
Units for this parameter n.
Linear calibration values in xx, yy order, for example: xx= channel number, yy =
channel value. When this value is "0.0, 0.0" the resolution of the data is used.
Calibration for parameter n is active. This value is always "ON".
Name of Parameter used as Ratio Denominator or "N/A" if ratio is not selected.
Name of Parameter used as Ratio Numerator or "N/A" if ratio is not selected.
Internal Multiplexer address of the parameters used for the Ratio Parameter
Denominator.
Internal Multiplexer address of the parameters used for the Ratio Parameter
Numerator.
Red laser power at end of acquisition.
Red laser power at start of acquisition.
Red laser shutter status.
Red laser target power.
Displays Runtime Protocol if the current file is exactly as at the end of acquisition, if
any changes are made post acquisition and the LMD file is resaved, the new file
displays New Protocol.
User defined string.
User defined string.
User defined string.
User defined string.
Instrument settings file used for acquisition.
The date and time of the instrument settings file used for acquisition.
Contains the reason why the acquisition was stopped. It can be one of the following
values:
"ERROR": Instrument error occurred
"PROTOCOL ": Event count or acquisition time limit met.
"MANUAL ": User selected stop.
"MAX EVENTS": Maximum events for the number of selected parameters reached.
"UNKNOWN": The stop reason is unknown.
Protocol file name.
Protocol name.
The tube number (location on the carousel) from which the data set was acquired.
Violet laser power at end of acquisition.
Violet laser power at start of acquisition.
Specifications 4
Software Specifications
4-13
