Interfaces; Input Devices; Monitor Options; Software Specifications - Beckman Coulter Navios Instructions For Use Manual

Interfaces

• Microsoft Windows Vista operating system.
• Bidirectional asynchronous serial interfaces for communication with mainframe and personal
computers.

Input Devices

• PS/2 optical Intellimouse
• Full size PS/2 keyboard.

Monitor Options

• Minimum requirement - color LCD with a 22-in. flat screen.
• Optional second monitor

Software Specifications

Data Output and Compatibility

Output and compatibility features include:
• Flow Cytometric Standard (FCS) file format for listmode and histogram files. Listmode files
contain an FCS 2.0 dataset followed by an FCS 3.0 dataset.
• Copy and Paste, or Drag and Drop plots images to third party programs such as MS Word.
• Full-color printouts with the appropriate optional Printer.
• Printout of sample results and patient reports with FlowPAGE and desktop printing
• PDF format for Acquisition printouts or FlowPAGE reports
• Printout of Worklist for the MCL
• Compatibility with ALTRA, Elite, XL
only)
• Export data to MS Excel 2003 or MS Excel 2007
• Save/export data as a text file.

Reporting Units

Reporting units for absolute count calibrators are cells/μL for US units or cells/L for SI units.

Absolute Count Determination

Absolute counts may be determined by two methods: the Flow-Count (SPT) Method (Direct Method)
and the Dual Platform Method (Standard or Indirect Method).
773232AH
,
XL-MCL and FC 500 flow cytometer files (listmode files
Specifications 4
Software Specifications
4-5
