Where:
C = Raw digital channel number
n
C = Channel count
ch
C = Channels per decade
d
N = Integral of all counts between & including marker channels
= Mean channel number (rounded to nearest whole channel)
For calibrated values, the Mean calculation is reported as a value in the range Log Offset to (Log
Decades Full Scale
offset* 10
The log offset cannot be zero since a log offset of zero is 10 (minus infinity). Since the graphical scale
is actually proportional to the exponent, it is not possible to represent this on paper or on screen.
Because of this problem, Navios software does not allow log offset values of less than 0.1. Numbers
entered in the Logarithmic Offset edit window are clamped at 0.1 if a number less than 0.1 is entered.
773232AH
) thus:
Operation Principles 3
Plot Display
3-17
