Using Navios Software
Cytometer Menu

Collection Angle

Select the required Forward Scatter Collection Angle for the Protocol. The FS Angle icon will toggle
between Wide angle (W), Enhanced Wide Angle (W2)and Narrow angle (N).
ND Filter
Activate

Cytometer Control Compensation Tab

Compensation allows for the subtraction of a
percentage of the signal of one fluorescence
detector from the signal of another
fluorescence detector to correct for the overlap
of one dye's emission into another dye's
detector.

Compensation Matrix

Clear All Button

You cannot make any changes on this screen
when running a

See also:

Cytometer Control

Cytometer Control Acquisition Setup Tab

Compensation Matrix
Click in the box and type a value or use the Slide Bar to set the desired value. Use the Up and Down
arrows to make any fine adjustments to the value.
Clear All Button
Selecting the

Status Page

To view the
verification tube of the application.
10-164
or deactivate Neutral Density Filters on the Side Scatter Detector.
locked protocol.
Clear All button resets ALL the values within the
cytosettings of an application, display or print the Cytometer Status screen for the
Compensation Matrix to zero.
773232AH
