Using Navios Software
Analysis Menu
Editing a Single Prism Divider
Editing an existing histogram plot with a set of single Prism dividers displayed essentially consists
of creating a new single Prism dividers. When the second single Prism dividers are defined, the
original is deleted.
1
Highlight the chosen histogram plot (click on the title bar).
2
Mouse over the Prism divider to get the
3
+ hold to set the new divider. The old divider is deleted and the display is once again
updated to show only one single Prism divider. Any associated Prism plot is updated with the
new Prism statistics.
4
To delete Prism divider,
divider for the associated parameter is deleted altogether from this plot and from any other
plot that has this divider set. Any associated Prism plot changes its format and its statistics are
updated to reflect a smaller number of Prism dividers.

View/Modify Prism

Under most circumstances, Prism is modified graphically by using Dual or Single Prism Divider
cursor operations. Occasionally, it is necessary to modify the Prism dividers numerically to
reproduce exactly the setup of another experiment. View/Modify Prism allows you to do this.
1
Analysis > View/Modify Prism
10-138
, or cursor.
on the divider to make it active and press
. The Prism Setup dialog box is displayed.
( ) ( )
. The Prism
Delete
773232AH
