When drawing or modifying Regions the status bar divides into three areas of information. These
update as a region is modified:
• The status bar shows Channel for X parameter
• The total integral count of the region
• The percentage of events currently within the region.
X Coordinate
The X Axis channel value is the coordinate of the cursor position given by a scaling factor. This
scaling factor depends on whether the Histogram parameter is using linear or logarithmic
amplification and whether you have calibrated that parameter or not.
If the parameter is linear and uncalibrated, the X channel varies between 0 - 255 or 0 - 1024
depending on the data source. If the parameter is logarithmic and uncalibrated, the value varies
between 0.1024 - 1024 and span four decades. For most other manufacturers, the data varies
between 1 - 10,000, spanning four decades also.

Integral

When you create a Region the status bar reflects the integral values given along the scale for that
parameter at the cursor position. That is, before the first marker is set.
If the cursor is on channel 10, the integral shows the count value of the populations at channel 10.
After first marker is set and as you move the mouse to either the left or right of this point, the
integral value continuously updates to reflect the summation of each channel between the Region
starting position and the current mouse position.

Multiple Linear Regions

This option sets multiple consecutive linear Regions on one display. When linear regions are created
using the Multiple Linear Regions option, gates are not created even though
Creation is selected in Workspace Preferences. See:

Interactive Multi-Linear Region Editing

When a Region's position is changed, any Gates that use the Region are automatically updated and
each plot is redrawn to reflect the changes in the Gate. When the Region is deleted any Gate which
used the Region is also automatically deleted. When a Gate has been deleted, any plot that used the
deleted Gate is reset to Ungated. Allows you to resize an already created Region.

View / Modify Regions

Use this option to view/edit a Region's properties, Region points or to delete a Region that is no
longer required.
773232AH
Multiple Linear Regions.
