Using Navios Software

Analysis Menu

combinations of Gates to define a unique subpopulation. Each Gate (up to three) is given a color and

the logical gate combinations give rise to populations with blended colors.

Consider three gates: Gate A, set on FL1 positive cells; Gate B, set on FL2 positive cells; Gate C, set on

FL3 positive cells. Any event may be in either none, one, two or all three of these Gates and

therefore, combinations of the gates may be used to define eight different subpopulations

(phenotypes) of events as follows:

Each of these subpopulations may be represented by a

different color. Thus up to eight differently colored

subpopulations may be visualized on a Color Gated Dot

Plot, and each group can be given a user defined name.

When in color blend mode ONLY color statistics from the blended colors are displayed in the Legend

plot. Use
