Signal Amplitude Indicators

NOTE
When both log and linear parameters are selected for the same sensor, the amplitude display defaults
to the log signal.
1. Blue indicates the signals from the 488 laser.
FS, SS, FL1, FL2, FL3, FL4 and FL5
2. Red indicates the signals from the 638 laser.
FL6, FL7 and FL8
3. Green indicates the signals from the 405 laser.
FL9 and FL10

Cytometer Ready and Sheath Flow Indicators

FLOW (ready when green)
STATUS (ready when green)
5-4
FLOW CLEANSE
STATUS
WASTE SHEATH
b
d
c
FLOW CLEANSE
STATUS
WASTE SHEATH
