PLANET Series Range Hood

Installation Guide

Operation Manual

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the PLANET Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elba PLANET Series

Page 1 PLANET Series Range Hood Installation Guide Operation Manual...
Page 2  The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.  Installation must be carried out by a qualified and authorized ELBA Service Technician.  The minimum safety distance between the cooktop and the range hood is 650 millimeters (mm).
Page 3 INSTALLATION Important Notes:  The hood should be placed at a distance of 65-75cm from the cooking surface for maximum performance.  The exhaust pipe should have a minimum diameter of 150 millimeters (mm)  Try to avoid too many corner bends when installing the exhaust pipe in order to ease airflow and noise.
Page 4 Models Without Glass Components: 1. Fix the lower/outer chimney bracket on to the wall by drilling two (2) holes with the corresponding size of the screws provided as seen in pic 2.  Note that this will be where the range hood is also mounted. 2.
Page 5 Models With Glass Components 1. Fix the lower/outer chimney bracket on to the wall by drilling two (2) holes with the corresponding size of the screws provided as seen in pic 2.  Note that this will be where the range hood is also mounted. 2.
Page 6 OPERATION Controls The switch is operated as illustrated.  “0”, press to turn off  “low”, press to activate speed setting 1  “middle” press to activate speed setting 2  “high”, press to activate speed setting 3  “light”, press to turn on, depress to turn off CLEANING AND MAINTENANCE Aluminum Filters This unit comes equipped with removable...
Page 7 LED Lights This unit comes equipped with energy efficient LED bulbs. Instruction:Please call the service centre for the replacement of the LED bulb modules. It is suggested that you do not try to replace this yourself, as it might cause electrical shock. Warranty Exemption: The incandescent bulbs are a consumable item and are not covered by the warranty of this item.
