AC adapter jack
PS/2 mouse
Figure 15. Port replicator
To install the eGO-note on a port replicator:
1. Turn off the eGO-note and open a docking connector
compartment door.
2. Press eject buttons on side edge of a port replicator. (Figure 16)
Eject
Button
Figure 16. Pressing the eject buttons on a Port replicator
3. Place the eGO-note straight on a port replicator and press
firmly. Then eject buttons pops out.(Figure 17)
Video port
PS/2
keyboard
USB port
Printer port
Serial port
Connecting Peripheral Devices 21
Locking
hook
Eject
Button
