ODIN-W2 series
Stand-alone multiradio modules with
Wi-Fi & Bluetooth
System Integration Manual
Abstract
This document describes the system integration of ODIN-W2 series
multiradio module. The ODIN-W2 module is a compact, stand-
alone, Wi-Fi IEEE 802.11-2012 (a/b/g/n), dual-band 2x2 MIMO,
Bluetooth v2.1+EDR, Bluetooth Low Energy v4.0, multiradio
solution in the compact ODIN form factor.
www.u-blox.com
UBX-14040040 - R03
Advertisement
Table of Contents
Related Manuals for u-blox ODIN-W260
Summary of Contents for u-blox ODIN-W260
- Page 1 This document describes the system integration of ODIN-W2 series multiradio module. The ODIN-W2 module is a compact, stand- alone, Wi-Fi IEEE 802.11-2012 (a/b/g/n), dual-band 2x2 MIMO, Bluetooth v2.1+EDR, Bluetooth Low Energy v4.0, multiradio solution in the compact ODIN form factor. www.u-blox.com UBX-14040040 - R03...
- Page 2 This document may be revised by u-blox at any time. For most recent documents, visit www.u-blox.com. Copyright © 2015, u-blox AG. u-blox® is a registered trademark of u-blox Holding AG in the EU and other countries. ARM® is the registered trademark of ARM Limited in the EU and other countries.
-
Page 3: Table Of Contents
ODIN-W2 series - System Integration Manual Contents Contents ..........................3 System description ....................... 5 Product features ........................... 5 Architecture ............................6 1.2.1 RF section ............................6 1.2.2 Host processor..........................6 Pin description ............................7 Operating modes ..........................9 1.4.1 Radio modes ..........................9 1.4.2 Power modes .......................... - Page 4 ODIN-W2 series - System Integration Manual Thermal guidelines..........................17 2.5.1 Thermal protection ........................17 2.5.2 Heat dissipation ........................... 17 ESD guidelines ............................ 18 Schematic for ODIN-W2 ........................18 Handling and soldering ..................... 20 Packaging, shipping, storage and moisture preconditioning ............... 20 Handling .............................
-
Page 5: System Description
ODIN-W2 series - System Integration Manual 1 System description The ODIN-W2 series is a highly integrated multiradio module developed by u-blox for integration in demanding, reliable devices such as those needed for industrial and medical applications. The module is built around a multiradio chip, which includes Wi-Fi, Classic Bluetooth and Bluetooth Low Energy (Dual Mode / Bluetooth Smart Ready). -
Page 6: Architecture
Different antenna options are available depending on the chosen ODIN-W2 series model: • ODIN-W260: A standard coaxial U.FL. connector that must be connected to an external antenna through a coaxial cable. See Antenna connectors section for more information about the antenna connectors. -
Page 7: Pin Description
ODIN-W2 series - System Integration Manual The power management is handled by a 1.8 V DC regulator that supplies the host core and IOs. The 1.8 V IO voltage is also available on the solder pads for use on an external interface logic. The 1.8 V is always available if the VCC supply to the module is stable. - Page 8 ODIN-W2 series - System Integration Manual Function Name Description Remarks Ground All GND pads must be connected to ground. System RESET_N External reset input. Internal active pull-up to V_INT. Logic Red LED Signal. Active low. GREEN/SWITCH_1 Logic Green LED Signal. Active low.
-
Page 9: Operating Modes
ODIN-W2 series - System Integration Manual 1.4 Operating modes 1.4.1 Radio modes The ODIN-W2 series is a stand-alone multiradio module that supports Wi-Fi, Bluetooth classic, and Bluetooth low energy. It can run as a single radio module with only one radio-mode enabled or as a true multiradio module with both Bluetooth and Wi-Fi enabled concurrently. -
Page 10: System Function Interfaces
ODIN-W2 series - System Integration Manual 1.6 System function interfaces 1.6.1 Module reset You can reset (reboot) the ODIN-W2 series modules using one of the following methods: • Hardware reset: Low level on the RESET_N pin, which is normally set high by an internal pull-up, for a valid time period (see ODIN-W2 series Data Sheet [2]). -
Page 11: Firmware Update
The antenna interface is different for each module version in the ODIN-W2 series. 1.7.1 Antenna connectors The ODIN-W260 module has two RF antenna U.FL. connectors with a characteristic impedance of 50 ohm. The main supports both Bluetooth and dual-band Wi-Fi. -
Page 12: Ethernet (Rmii+Smi)
ODIN-W2 series - System Integration Manual The following UART signals are available: • Data lines (RXD as input, TXD as output) • Hardware flow control lines (CTS as input, RTS as output) The UART can be used as both 4 wire UART with hardware flow control and as 2-wire UART with only TXD and RXD. - Page 13 ODIN-W2 series - System Integration Manual The following two types of ground (GND) pads are available: • GND pads and the PCB edge (castellations): Mainly for power supply return path and RF ground. • Heat dissipation GND pads under the module: Mainly used for dissipation of heat, especially during intensive Wi-Fi activity.
-
Page 14: Design-In
ODIN-W2 series - System Integration Manual 2 Design-in 2.1 Design guidelines 2.1.1 Module supply (VCC) design Good connection of the module’s VCC pin with DC supply source is required for correct RF performance. The guidelines are summarized below: • VCC connection must be as wide and short as possible. •... -
Page 15: Antenna Connectors
Keep a minimum clearance of 5 mm between the antenna and the casing. Keep a minimum 10 mm free space from metal around the antenna including under. If a metal enclosure is required, ODIN-W260 with antenna connectors has to be used. -
Page 16: Module Placement
ODIN-W2 series - System Integration Manual positioned along one side of the host PCB ground plane is the second best option. It is beneficial to have a large ground plane on the host PCB and have a good grounding on the ODIN- W2 module. Figure 5: ODIN-W262 internal antenna 2.3 Module placement An optimized module placement allows better RF performance. -
Page 17: Thermal Guidelines
ODIN-W2 series - System Integration Manual Figure 6: ODIN-W2 series footprint These are recommendations only and not specifications. The exact mask geometries, distances and stencil thicknesses must be adapted to the specific production processes (for example, soldering and so on) of the customer. -
Page 18: Esd Guidelines
ODIN-W2 series - System Integration Manual • Optimize the thermal design of any high power component included in the application, such as linear regulators and amplifiers to minimize the temperature distribution in the application device. • Select the material, thickness and surface of the mechanical enclosure of the end product in such a way that it provides good thermal dissipation. - Page 19 ODIN-W2 series - System Integration Manual Figure 7: A complete ODIN-W2 design in a 3.3 V application UBX-14040040 - R03 Advance Information Design-in Page 19 of 33...
-
Page 20: Handling And Soldering
3.1 Packaging, shipping, storage and moisture preconditioning For information pertaining to the ODIN-W2 series reels/tapes, Moisture Sensitivity levels (MSL), shipment and storage information, and drying for preconditioning, refer to ODIN-W2 series Data Sheet [2] and u-blox Package Information Guide [3]. -
Page 21: Reflow Soldering
ODIN-W2 series - System Integration Manual Soldering Paste OM338 SAC405 / Nr.143714 (Cookson Electronics) Alloy specification 95.5% Sn / 3.9% Ag / 0.6% Cu (95.5% Tin / 3.9 % Silver / 0.6% Copper) 95.5% Sn / 4.0% Ag / 0.5% Cu (95.5% Tin / 4.0% Silver / 0.5% Copper) Melting Temperature 217°C 150 μm for base boards... -
Page 22: Optical Inspection
ODIN-W2 series - System Integration Manual Figure 8: Recommended soldering profile The modules must not be soldered with a damp heat process. 3.3.3 Optical inspection After soldering the ODIN-W2 series modules, inspect the modules optically to verify that the module is properly aligned and centered. -
Page 23: Rework
EMI covers is done at the customer's own risk. The numerous ground pins should be sufficient to provide optimum immunity to interferences and noise. u-blox gives no warranty for damages to the modules caused by soldering metal cables or any other forms of metal strips directly onto the EMI covers. -
Page 24: Qualifications And Approvals
ODIN-W2 series - System Integration Manual 4 Qualifications and Approvals The ODIN-W2 series modules are in Advance Information status as mentioned in Document status explanation section. Hence, the following information is not fully valid and completed yet but will be when the module is fully tested and approved in the Production Information stage as mentioned in the Document status section: •... -
Page 25: Ul Listing Information
The recommended size of the Giteki mark is Ø5.0 mm but the minimum size is Ø3.0 mm. The end product holder should also include a copy of the Japan Radio Certificate to the end product technical documentation. Contact support@u-blox.com for a copy of the Radio Certificate. 4.5 Compliance with RoHS directive The ODIN-W2X product is produced according to the RoHS (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment) directive and complies with the directive. -
Page 26: Appendix A - Glossary
ODIN-W2 series - System Integration Manual Appendix A - Glossary Name Definition Analog to Digital Converter Band Pass Band Pass Filter Bluetooth Controller Area Network Clear To Send Direct Current Data Set Ready Data Terminal Ready ElectroStatic Discharge Firmware Ground GPIO General Purpose Input Output High... -
Page 27: Appendix B - Antennas
ODIN-W2 series - System Integration Manual Appendix B - Antennas Antenna accessories Name U.FL to SMA adapter cable Connector U.FL and SMA jack (outer thread and pin receptacle) Minimum cable length 120 mm Minimum cable loss 0.5 dB, The cable loss must be above the minimum cable loss to meet the regulatory requirements Comment The SMA connector can be mounted in a panel... -
Page 28: Approved Antennas
ODIN-W2 series - System Integration Manual Approved antennas Single band antennas Ex-IT 2400 RP-SMA 28-001 Manufacture ProAnt Polarization Vertical Gain +3.0 dBi Size Ø 12.0 x 28.0 mm Reverse Polarity SMA plug (inner thread and pin receptacle). To be mounted on the U.FL to Connector Reverse Polarity SMA adapter cable. - Page 29 ODIN-W2 series - System Integration Manual InSide-2400 Manufacture ProAnt Gain +3.0 dBi Size 27 x 12 mm (triangular) Cable length 100 mm Connector U.FL. connector Comment To be mounted on the U.FL connector on the PCB. Approval FCC, IC, R&TTE and MIC FlatWhip-2400 Manufacture ProAnt...
- Page 30 ODIN-W2 series - System Integration Manual Dual-band antennas InSide-WLAN Manufacture ProAnt Gain +3.0 dBi Size 27 x 12 mm (triangular) Cable length 100 mm Connector U.FL. connector Comment Dual-band (2.4 GHz / 5 GHz) antenna to be mounted on the U.FL connector on the PCB.
-
Page 31: Appendix C - Design-In Checklist
ODIN-W2 series - System Integration Manual Appendix C – Design-in checklist Schematic checklist Status Description Reserved pins not connected. Correct voltage level for all interfaces. Verify the startup sequence. Errata reviewed for all chips and modules. VCC supply must be provided and stay within operating conditions. External LPO_CLK must stay within operating conditions, if applied. -
Page 32: Related Documents
ODIN-W2 AT Commands Manual, document number UBX-14044127 ODIN-W2 series Data Sheet, document number UBX-14039949 u-blox Package Information Guide, document number UBX-14001652 For regular updates to u-blox documentation and to receive product change notifications, register on our homepage (http://www.u-blox.com). Revision history... -
Page 33: Contact
ODIN-W2 series - System Integration Manual Contact For complete contact information visit us at www.u-blox.com. u-blox Offices North, Central and South America Headquarters Asia, Australia, Pacific Europe, Middle East, Africa u-blox America, Inc. u-blox Singapore Pte. Ltd. u-blox AG Phone:...
