- Page 1 BNI IOL-101-000-K018 BNI IOL-102-000-K019 BNI IOL-101-S01-K018 BNI IOL-102-S01-K019 User’s Guide...
-
Page 2: Table Of Contents
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 1 Notes for the user About this guide Structure of the guide Typographical conventions 1.3.1 Enumerations 1.3.2 Actions 1.3.3 Syntax 1.3.4 Cross references Symbols Abbreviations 2 Safety... -
Page 3: Notes For The User
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Notes for the user 1.1 About this guide This guide describes the Balluff IO-Link sensor collector module, also called Sensor hub. Connection to the host interface master is made through the IO-Link protocol. Functionally this compact, cost-effective module is comparable with a passive splitter box: It takes conventional sensor signals and passes them over the IO-Link interface. -
Page 4: Safety
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Safety 2.1 Intended use This guide describes the Balluff IO-Link sensor collector module, also called Sensor Hub. Connection to the host interface master is made through the IO-Link protocol. Functionally this compact, cost-effective module is comparable with a passive splitter box: It takes conventional sensor signals and passes them over the IO-Link interface. -
Page 5: Getting Started
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Getting started 3.1 Connection overview 8 port module Figure 3-1: BNI IOL-102-000-K019 / BNI IOL-102-S01-K019 1 IO-Link interface 8 Mounting hole 2 Mounting hole 9 Port LED: Standard input port 7, Pin 4... -
Page 6: Connection Overview 4 Port Module
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Getting started 3.2 Connection overview 4 port module Figure 3-2: BNI IOL-101-000-K018 / BNI IOL-101-S01-K018 1 IO-Link interface 2 Mounting hole 3 Status LED: Communication / module... -
Page 7: Mechanical Connection
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Getting started The BNI IOL … modules are attached by using 2 M4 screws and 2 spacers. 3.3 Mechanical connection 3.4 Electrical The sensor hub modules require no separate supply voltage connection. Power is provided connection through the IO-Link interface by the host IO-Link master. -
Page 8: Io-Link Interface
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 IO-Link interface 4.1 IO-Link data BNI IOL-101-000-K018 / BNI IOL-102-000-K019 Data transmission rate COM2 (38,4 kBaud) Frame type Minimal cycle time 2.5 ms Process data cycle time 2.5 ms, at minimal cycle time... -
Page 9: Process Data / Output Data
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 IO-Link interface 4.3 Process data / Input data BNI IOL-101-000-K018, 4 binary inputs BNI IOL-101-000-K018 Byte 0 Signal port (x): x.0: Pin 4, BNI IOL-102-000-K019, 8 binary inputs... -
Page 10: Parameter Data / Request Data
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 IO-Link interface 4.4 Parameter data / Request data SPDU Object name Length Range Default value Sub- Index Index Index 0x07 Vendor ID 2 Byte 0x0378 0x08 0x09... -
Page 11: Errors
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 IO-Link interface 4.5 Errors Error Code Additional Code Device application Index not available error 0x80 0x11 Device application Subindex not available error 0x80 0x12 Device application Value out of range... -
Page 12: Technical Data
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Technical data 5.1 Dimensions Figure 5-1: BNI IOL-101-xxx-K018 Figure 5-2: BNI IOL-102-xxx-K019 BNI IOL-101-000-K018 BNI IOL-102-000-K019 BNI IOL-101-S01-K018 BNI IOL-102-S01-K019 5.2 Mechanical Housing material Plastic data IO-Link port... -
Page 13: Operating Conditions
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Technical data 5.4 Operating Operating temperature -5 °C ... 55 °C conditions Storage temperature -25 C ... 70 °C 2004/108/EC Immunity test: EN 61000-6-2 Emission test: EN 61000-6-4... - Page 14 Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Technical data LED I-ports BNI IOL-101-000-K018 / BNI IOL-102-000-K019 Standard LED 1, I-port Pin 4 Indication Function Yellow, solid Input signal = 1 Input signal = 0...
-
Page 15: Appendix
Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 Appendix Product ordering code BNI IOL-10x-x0x-K01x Balluff Network Interface IO-Link interface Function 101 = 4 port 102 = 8 port Variants 000 = Standard version S01 = with single channel monitoring... - Page 16 Balluff Network Interface / IO-Link Sensor hub M8 BNI IOL-101…K018 / BNI IOL-102…K019 www.balluff.com Balluff GmbH Schurwaldstrasse 9 73765 Neuhausen a.d.F. Germany Tel. +49 7158 173-0 Fax +49 7158 5010 balluff@balluff.de www.balluff.com...
