- Page 1 “CARRINGTON” （FAUX） SLATE FIREPLACE FA874900TX—IVORY FA875200TX—BLACK FA875500TX—CLASIC MAHOGANY For assistance with assembly contact: FA875600TX—WHITE Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
- Page 2 (FAUX) SLATE FP (WITH CONVERTIBLE TOP) Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 (FAUX) SLATE FP (WITH CONVERTIBLE TOP) Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 (FAUX) SLATE FP (WITH CONVERTIBLE TOP) Assembly Instructions INSERT 4PCS WOOD DOWEL (B) & 4PCS CAM BOLT(A) ONTO CORRESPONDING HOLE OF LEFT AND RIGHT FRONT PANEL(3),THEN INSERT 4PCS CAM-LOCKS (C) INTO BIG HOLES OF UPPER&BELOW FRONT PANELS(4.5) WITH SLOT FOR SCREWDRIVER FACING OUTWARD.
- Page 5 (FAUX) SLATE FP (WITH CONVERTIBLE TOP) Assembly Instructions INSERT 7PCS CAM BLOT (A) AND 4PCS WOOD DOWEL (B) INTO PREDRILLED HOLES OF TOP PANEL(1),AND THEN INSERT 7PCS CAM-LOCK(C) INTO BIG HOLES OF SIDE PANEL AND FRONT PANEL AND UPPER FRONT PANEL(2.3.4) TO ASSEMBLE TOP PANEL(1) AND PREASSEMBLED FRAME TOGETHER.AS FIGURE4 SHOWN.
- Page 6 (FAUX) SLATE FP (WITH CONVERTIBLE TOP) Assembly Instructions INSERT FIREBOX FROM THE BACK OF FIREPLACE. MAKE SURE FIREBOX IS PRESSED TIGHTLY AGAINST THE ASSEMBLED UNIT. ATTACH WOOD HOLDERS (7) ON THE SIDES OF FIREBOX. INSERT 4PCS FLAT HEAD LONG SCREW (D) THROUGH PREDRILLED HOLES ON WOOD HOLDER (7) AND TIGHTEN INTO CORRESPONDING HOLES ON BACK OF...
- Page 7 Please contact the retailer that you purchased from for returns. We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com and we might feature it on our site or use it to model one of our inspirational photos.
