- Page 1 "LINDA"CORNER FIREPLACE FA8514 - CLASSIC MAHOGANY FA8515 – ANTIQUE WHITE For assistance with assembly contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 "LINDA"CORNER FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
-
Page 3: Side Panel（L&R
"LINDA"CORNER FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 4 "LINDA"CORNER FIREPLACE Assembly Instructions INSERT 2PCS WOOD DOWEL (B) AND 2PCS CAM BOLT (A) INTO PREDRILLED HOLES ON END OF LEFT AND RIGHT FRONT PANELS (1) AND FIT INTO CORRESPONDING HOLES OF LOWER FRONT PANEL(2),THEN INSERT 2PCS CAM-LOCK (C) INTO BIG HOLES ON EDGES OF LOWER FRONT PANEL(2) WITH SLOT FOR SCREWDRIVER FACING...
- Page 5 "LINDA"CORNER FIREPLACE Assembly Instructions INSERT 8PCS WOOD DOWEL (B) AND 10PCS CAM BOLT (A) INTO PREDRILLED HOLES ON INSIDE OF LEFT AND RIGHT FRONT PANELS (1) AND FIT INTO CORRESPONDING HOLES OF SIDE PANEL, THEN INSERT 10PCS CAM-LOCK (C) INTO BIG HOLES ON EDGES OF LEFT AND R GHT SIDE PANELS (4) WITH SLOT FOR SCREWDRIVER FACING...
- Page 6 "LINDA"CORNER FIREPLACE Assembly Instructions USE 3PCS HINGE (F) AND 12PCS FLAT HEAD SCREW (E) TO ASSEMBLE TRIANGLE TOP PANEL (8) AND TOP FRAME (5) TOGETHER AS FIGURE7 SHOWN. Figure 7 INSERT THE FIREBOX FROM THE BACK OF FIREPLACE. MAKE SURE FIREBOX IS PRESSED TIGHTLY AGAINST THE ASSEMBLED UNIT.
- Page 7 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI. The fireplace mantel will fit both gel fuel and electric firebox inserts. Depending on the insert ordered only one insert will be included.
