- Page 1 "TERRI"FIREPLACE FA8546AO – PLANTATION OAK FA8547AO - CLASSIC MAHOGANY For assistance with assembly contact: FA8548AO – ANTIQUE WHITE Southern Enterprises Inc. FA8549AO - BLACK Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com...
- Page 2 "TERRI"FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage.
- Page 3 "TERRI"FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage.
- Page 4 "TERRI"FIREPLACE Assembly Instructions USE GLUE TO FILL 1/4 HOLE OF FRONT/ BACK RAIL & WOOD CONNECTOR (11,12 &13). INSERT 3PCS CAM-BOLT (A), AND 12PCS WOOD DOWEL (B) INTO PREDRILLED HOLES ON FRONT AND BACK RAILS (11&12) , AND FIT INTO CORRESPONDING HOLES ON ENDS OF WOOD CONNECTER (13).
- Page 5 "TERRI"FIREPLACE Assembly Instructions INSERT 2PCS CAM-BOLTS (A) AND 6PCS WOOD DOWELS (B) INTO PREDRILLED HOLES ON UPSIDE OF BASE (2) AND FIT INTO CORRESPONDING HOLES ON BOTTOM EDGES OF THE ASSEMBLED UNIT. INSERT 2PCS CAM-LOCKS (C) INTO BIG HOLES ON INSIDE OF LEFT AND RIGHT SIDE PANELS (6&7)
- Page 6 "TERRI"FIREPLACE Assembly Instructions INSERT 17PCS WOOD SCREWS THROUGH PREDRILLED HOLES ON PARTS (8,9,10) AND TIGHTEN IT CLOCKWISELY. Figure 7 PLACE TOP PANEL (1) ONTO TOP EDGES, ATTACH IT TO THE UNIT BY USING 9PCS FLAT HEAD LONG SCREW (D) AS FIGURE 8 SHOWN.
- Page 7 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI. The fireplace mantel will fit both gel fuel and electric firebox inserts. Depending on the insert ordered only one insert will be included.
