- Page 1 FA8575- "ELINGTON"FIREPLACE BROWN MAHOGANY For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 "ELINGTON"FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 "ELINGTON"FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 "ELINGTON"FIREPLACE Assembly Instructions INSERT 4PCS WOOD DOWEL(B)& 6PCS CAM BOLT(A) ONTO CORRESPONDING HOLE OF FRONT PILLARS(1),THEN INSERT 6PCS CAM-LOCKS (C) INTO BIG HOLES ON INSIDE OF SIDE PANELS(2) WITH SLOT FOR SCREWDRIVER FACING OUTWARD. ROTATE CAM-LOCKS (C) CLOCKWISE TO SECURE CAM-BOLTS (A).
- Page 5 "ELINGTON"FIREPLACE Assembly Instructions INSERT 4PCS WOOD DOWEL (B) & 2PCS CAM BOLT(A) ONTO CORRESPONDING HOLE OF UPPPDER CROSS BAR & LOWER CROSS BAR (5&7),THEN INSERT 2PCS CAM-LOCKS (C) INTO BIG HOLES OF RIGTH AND LEFT BACK PANELS(6) WITH SLOT FOR SCREWDRIVER FACING OUTWARD.
- Page 6 "ELINGTON"FIREPLACE Assembly Instructions PUT FIXBOX SUPPORT (10) ONTO CORRESPONDING FRAME, AND FIX IT BY 6PCS FLAT HEAD LONG SCREW (D). Figure 7 INSERT FIREBOX FROM THE BACK OF FIREPLACE. MAKE SURE FIREBOX IS PRESSED TIGHTLY AGAINST THE ASSEMBLED UNIT. ATTACH THE FIXED WOOD (11) ON THE SIDES OF FIREBOX.
- Page 7 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI. The fireplace mantel will fit both gel fuel and electric firebox inserts. Depending on the insert ordered only one insert will be included.
