Seville Classics SHE14155 Assembly Instructions

Please make sure you have all the parts before assembly
A 4 pcs B 4 pairs
Poles Slip-Sleeves
E 4 pcs F 4 pcs
Threaded Inserts
Stacking Connectors
C 4 pcs D
Leveling Feet
Step 1:
Screw Leveling Feet (C) into the bottom
of the poles with Threaded Inserts (F).
Step 2:
On the top of each pole, fasten a pair of
Slip-Sleeves (B) around the grooves at
the desired shelf height.
1 pc
Shelf
Step 3:
Slide the Shelf (D) over the top of the four
poles until it rests snugly over the slip-sleeves.
For Stacking Purposes Only
requires 2 or more units
Step 4:
For stacking with two or more units, replace
the Threaded Inserts (F) with the Stacking
Connectors (E) into the bottom of the poles
of top unit. Remove the black plastic top
caps from the top of the poles on the bottom
unit and screw the poles of both units
together. Next, reattach the top shelf on the
top of the stacked unit.
TF150323
