9.3 befoRe sTaRTInG THe InTeRCoM

Channel "A" Button
Your SRC-System headset has two buttons designated for quick con-
nection to two other headsets. These other headsets are referred to as
CHaNNEl "a" and CHaNNEl "b".
Before you can begin using the intercom for Bike-to-Bike communica-
tion with one or two other headsets, all units must first be paired.
9.4 UsInG THe SRC-SySTEM foR InTeRCoM WITH oTHeR

SRC-SySTEM HeaDseTs

INTERCOM PaIRING / CONNECTION
CHaNNEl bUTTON
CHANNEL "A" CHANNEL "A" BUTTON
CHANNEL "B" CHANNEL "B" BUTTON
9.4a. TwO-waY INTERCOM PaIRING OPTIONS bETwEEN TwO
PaRTICIPaNTS
Using two SRC-System headsets
1.While both headsets are turned OFF, turn them ON by pressing and
holding the Mobile Buttons until the Blue Lights flash three times.
2. Make sure that both headsets are now flashing slowly in Blue.
3. Choose an available CHANNEL you wish to use to pair the headset
(CHANNEL "A" or CHANNEL "B").
QG SRC 131 - QG0160.indd 33
Channel "B" Button
PaIRING MOdE lEd
INdICaTORS
Rapid RED flashing
Rapid BLUE flashing
NOTE: Selecting a CHANNEL that is already in use will override the paired
headset on that CHANNEL with the newly paired headset.
4. On the SRC-System headset, press and hold the assigned CHAN-
NEL BUTTON ("A" or "B") for at least six seconds until the headset's
BLUE or RED Light begins flashing rapidly, indicating it is in Inter-
com Pairing mode. (See Intercom Channel Table for Pairing LED
indication for each CHANNEL)
5. Repeat Step 3-4 for the second SRC-System.
6. Within a few seconds, both headsets will show a solid light for two
seconds, indicating that the two headsets are now paired, con-
nected and ready for use.
NOTE: If the Pairing process is not completed within two minutes the
headset will return to Standby mode.
Initiate Intercom calls
There are two ways to start an Intercom call with your paired headset
while the headset is in Standby mode:
VOICE CONNECT:
Start talking loudly
Once you start talking loudly, an Intercom call will
be established with the other paired headset.
The Intercom call will stay on until all participants
remain silent for 30 seconds.
9.4b. THREE-waY INTERCOM
The SRC-System offers three-way intercom conference connectivity
as follows:
CHaNNEl bUTTON
CONNECT:
Tap the chosen
CHaNNEl button once
to add or remove the
other headset from an
Intercom call.
33
