Oontz Angle 3XL ultra Quick Start Manual

The powerful & portable wireless bluetooth speaker
Hide thumbs Also See for Angle 3XL ultra:
Table of Contents

Advertisement

Quick Links

See also: User Manual
The Powerful & Portable
Wireless Bluetooth Speaker
Quick Start Guide
TheOontZ.com
Designed and Engineered By

Advertisement

Table of Contents
loading

Related Manuals for Oontz Angle 3XL ultra

Summary of Contents for Oontz Angle 3XL ultra

  • Page 1 The Powerful & Portable Wireless Bluetooth Speaker Quick Start Guide TheOontZ.com Designed and Engineered By...

  • Page 2: Table Of Contents

    11 - 12 Playing From Non-Bluetooth Audio Source Devices Using the 3.5mm Audio Cable OontZ Wireless Dual Stereo for playing from a second OontZ Angle 3XL ULTRA OontZ Wireless Dual Stereo Setup -- Step 1 OontZ Wireless Dual Stereo Setup -- Step 2...

  • Page 3: In The Package

    In the Package Quick Start Guide 3.5mm Audio Cable (1.5 meter long) Power Adapter (Dual Voltage) Page 1...

  • Page 4: Buttons

    Buttons Power Track Back Track Forward Volume Up - Press and Release to go - Press and Release - Press to increase volume back to start of track to Play Next Track - Press and Release again to go to Previous Track Bluetooth Play/Pause Volume Down...

  • Page 5: Lights

    Blue Light lit when speaker is on: White Light lit when in OontZ Wireless Dual Stereo: - Flashing Blue - With a second OontZ Angle 3XL ULTRA speaker (sold separately) speaker is in pairing mode you can wirelessly connect both speakers together to play with - Solid Blue incredible stereo separation or playing full stereo in separate areas.

  • Page 6: Connectors - Back Of Speaker

    OontZ Wireless Dual Stereo Switch (Dual Function) When playing from one OontZ Angle 3XL ULTRA the switch allows you to select an optimized EQ: - When playing inside, we recommend sliding the switch to the left for “Indoor” setting EQ - When playing outside, we recommend sliding the switch to the right for “Outdoor”...

  • Page 7: Inside The Oontz Angle 3Xl Ultra

    Inside the Three Passive Bass Radiators OontZ Angle 3XL ULTRA Two custom tweeters Two large 2.75” precision drivers Page 5...

  • Page 8: Battery Features

    Automatic Turn Off - Conserves Battery Charge - When playing from battery power the OontZ Angle 3XL ULTRA will turn off after 30 minutes of not playing audio to conserve the battery charge. * - With the power adapter connected to the speaker and plugged into a wall outlet, the OontZ Angle 3XL ULTRA will remain on until you turn the power off.

  • Page 9: Charging The Battery

    Charging the Battery To charge the OontZ Angle 3XL Red Light lit when charging: ULTRA battery: - Slowly flashing Red - Plug the connector end of the Power Adapter battery is charging into the Charging Jack. - Solid Red - Plug the Power Adapter into a wall outlet.

  • Page 10: Turning On And Off

    Turning On and Off Turn ON - Red Light will turn on for 3 seconds (Will remain lit when the power adapter is plugged in) - Blue Light will turn on after 3 seconds indicating the speaker is on - Press and Release the Power Button Flashing Blue - The speaker is in pairing mode Solid Blue - The speaker is connected to a source device and ready to play Turn OFF...
  • Page 11 - The OontZ Angle 3XL ULTRA has automatically reconnected to the last device it was connected to and is ready to play. - The OontZ Angle 3XL ULTRA will automatically try to connect to the last device it was connected to each time it is turned on and that device is within range.*...

  • Page 12: Pair & Connect -- Step 2

    Important: Make sure the volume level is set high on your iPhone, iPad, iPod, Smartphone, Tablet, or Mobile Device. The volume on the OontZ Angle 3XL ULTRA and your device both need to be set to the highest level for the loudest volume.

  • Page 13: From Your Amazon Echo Dot Or Amazon Echo

    - Select your Amazon Echo Dot/Echo under 'Devices' by pressing it - Press 'Bluetooth' - Select the 'OontZ Angle 3XL Uxxx' (xxx: 3 characters unique to your speaker) when it appears in the list of 'Available Speakers' - Alexa will announce: "Connected to OontZ Angle 3XL Uxxx"...
  • Page 14 - or say "Alexa, disconnect my speaker" and the OontZ Angle 3XL ULTRA will automatically turn off after 30 minutes. - When you want to connect and play to the speaker again turn on the OontZ Angle 3XL ULTRA and say "Alexa, connect my speaker"...

  • Page 15: Playing From Non-Bluetooth Audio Source Devices Using The 3.5Mm Audio Cable

    Playing From Non-Bluetooth Audio Source Devices Using the 3.5mm Audio Cable - Make sure your OontZ Angle 3XL ULTRA battery has a sufficient charge Turn ON your OontZ Angle 3XL ULTRA Note: The Bluetooth on the OontZ Angle 3XL ULTRA is disabled when the 3.5mm audio cable is plugged in to...

  • Page 16: Oontz Wireless Dual Stereo For Playing From A Second Oontz Angle 3Xl Ultra

    OontZ Wireless Dual Stereo for playing from a second OontZ Angle 3XL ULTRA - With a second OontZ Angle 3XL ULTRA speaker (sold separately) you can wirelessly connect and play both speakers together. - Quickly and easily connect the two speakers to play together up to 100 feet apart* for:...

  • Page 17: Oontz Wireless Dual Stereo Setup -- Step 1

    - Set both speakers to either Left Channel - Right Channel or Dual Stereo - To set for Left Channel - Right Channel slide the OontZ Wireless Dual Stereo Switch to the left position on both speakers - To set for Dual Stereo slide the OontZ Wireless Dual Stereo Switch to the right position on both speakers Note: You can switch between Left Channel - Right Channel or Dual Stereo at any time, even when playing, by sliding the switch to the opposite position on both speakers.

  • Page 18: Oontz Wireless Dual Stereo Setup 2

    OontZ Wireless Dual Stereo Setup -- Step 2 – With both OontZ Angle 3XL ULTRA speakers turned on, connect one of the speakers to your device (see page 9). This speaker will serve as the Play Control Speaker while the two speakers are paired together in OontZ Wireless Dual Stereo.

  • Page 19: Oontz Wireless Dual Stereo - Important Notes

    OontZ Wireless Dual Stereo - Important Notes Play Control Speaker – Use the play buttons on the Play Control Speaker to adjust volume, play/pause, track back, track forward, answer and end phone calls. These controls are disabled on the second speaker when paired together.

  • Page 20: Oontz Wireless Dual Stereo - Important Notes

    OontZ Wireless Dual Stereo - Important Notes (continued) Turning the Speakers off – Turning the Play Control Speaker off will turn both speakers off. Turning the second speaker off first will only turn that speaker off and the Play Control Speaker will play as a single speaker.

  • Page 21: Ipx5 Water Resistant

    IPX5 rating - The OontZ Angle 3XL ULTRA can resist gentle water spray & splash but cannot be partially or fully submerged or left in a wet environment for an extended period of time, any of which could cause unrepairable damage to the speaker.

  • Page 22: Wireless Hands Free Personal Speakerphone

    - You can use your Smartphone or iPhone to switch between using Hands Free Speakerphone and your phone. - When two speakers are paired together in OontZ Wireless Dual Stereo, calls will come through the Play Control Speaker only and only the mic on the Play Control Speaker will be active.

  • Page 23: Safety And Precautions

    Safety and Precautions When the power adapter is connected to the OontZ Angle 3XL ULTRA speaker and plugged in to a wall outlet, never use the speaker in the shower, bath, rain or near water, to prevent risk of electric shock. Always unplug the power adapter from the speaker and wall outlet before the speaker is placed near or exposed to water or rain.

  • Page 24: Product Support & Customer Support

    TheOontZ.com Product Support For questions or issues with your OontZ Angle 3XL ULTRA, please view our troubleshooting tips at: TheOontZ.com/troubleshooting and select the OontZ Angle 3XL ULTRA Customer Support For additional support with your questions or issues, our Customer Support Team wants to assist you.
