Half-size PCI CPU Card supports Intel® Pentium® M/ Celeron® M with
a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0
PICO-8522
Quick Installation Guide
Version 2.0
Dec.09, 2008
Package List
PICO-8522 package includes the following items:
1 x PICO-8522 Single Board Computer
1 x Mini Jumper Pack
1 x ATA flat cable
1 x PS/2 KB/MS Y cable
1 x Dual RS-232 cable with bracket
1 x SATA cable
1 x Dual ports USB cable with bracket
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for IEI Technology PICO-8522
Summary of Contents for IEI Technology PICO-8522
-
Page 1: Quick Installation Guide
PICO-8522 Quick Installation Guide Version 2.0 Dec.09, 2008 Package List PICO-8522 package includes the following items: 1 x PICO-8522 Single Board Computer 1 x Mini Jumper Pack 1 x ATA flat cable 1 x PS/2 KB/MS Y cable 1 x Dual RS-232 cable with bracket... -
Page 2: Specifications
Specifications Socket 479 Intel® Pentium® M/ Celeron® M with 400 MHz FSB System Chipset: Intel® 852GM + ICH4M BIOS: AMI BIOS System memory: 1x 184-pin DIMM DDR 266/200MHz up to 1GB Ethernet Dual PCI interface Realtek RTL8110SC GbE controllers 2 x RS-232 5 x USB 2.0 (1 on bracket, 4 on board) 1 x 40 pin IDE 2 x SATA... -
Page 3: Ordering Information
Ordering Information PICO-8522-R20 Half-size PCI CPU Card supports Intel® Pentium® M/ Celeron® M with a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0 PICO-8522-1GZ-R20 Half-size PCI CPU Card supports Intel® Celeron® M 1GHz/ zero cache with a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0 PICO-8522-600-R20 Half-size PCI CPU Card supports Intel®... -
Page 4: Jumpers Setting And Connectors
Jumpers setting and Connectors LABEL FUNCTION J_CMOS1 Clear CMOS setup jumper J_VLVDS1 LVDS Voltage Selection jumper J_CF1 CF Card Master/Slave jumper LVDS1 Panel Resolution Selection jumper KB_MS1 PS/2 MOUSE & KEYBOARD Connector USB_C4 USB Port Connector LAN1 LAN RJ-45 Connectors LAN2 VGA1 VGA 15-pin Female Connector... - Page 5 J_VLVDS1 :LVDS Voltage Selection J_CMOS1 : Clear CMOS Setup J_VLVDS DESCRIPTION J_CMOS1 DESCRIPTION Set The Voltage Level Of Keep CMOS Setup (Default) Panel To 3.3V (Default) (Normal Operation) Set The Voltage Level Of Clear CMOS Setup Panel To 5V J_CF1 : configure CF Card type J_CF1 DESCRIPTION Open...
- Page 6 COM1, COM2: Internal Serial Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DSR# DCD# RTS# CTS# DTR# CPU_FAN1 : CPU Fan Connector PIN NO. DESCRIPTION +12V Sense Rotation Signal DIO1 : Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Ground Output 3 Output 2...
- Page 7 USB01 USB23: Internal USB Connector ¡ ¡ ¡ ¡ USB1 USB2 ¡ ¡ ¡ ¡ PIN DESCRIPTION DESCRIPTION GROUND DATA- DATA+ DATA+ DATA- GROUND INVERTER1 : 5-pin Header Inverter Connector PIN NO. DESCRIPTION LCD Adjust GROUND +12V GROUND BACKLIGHT ENABLE LVDS1: LVDS Connector PIN NO.
- Page 8 KB_MS2: 6-pin Header KB/MS Connector DESCRIPTION VCC(+5V) MOUSE DATA MOUSE CLOCK KB DATA KB CLOCK BAT1 : Battery Connector DESCRIPTION BAT+ (+3.3V) BAT- (GND) LPT1 : Parallel Port Connector DESCRIPTION DESCRIPTION RSTROBE# AUTO FORM FEED # DATA0 ERROR# DATA1 INITIALIZE# DATA2 PRINTER SELECT IN# DATA3...
-
Page 9: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
