1. Introduction Thank you for your purchase of the Ambient Weather WS14 Wireless 8-Channel Thermometer with Daily Min/ Max Display. The following user guide provides step by step instructions for installation, operation and troubleshooting. To download the latest manual and...
Image Item Number Description 8-channel sensor measures p r o b e t e m p e r a t u r e . F007TP A p p l i c a t i o n s i n c l u d e refrigerators and freezers (where the probe is placed inside the appliance(s) and...
2.1 Parts List Item Display Console Frame Dimensions (LxHxW): 4.00 x 2.95 x 1.00 in LCD Dimensions (LxW): 1.96x1.77” LCD Segment Height: 0.78 inches User Manual 3. Display Console Set Up Move the remote thermometer(s) about 5 to 10' away from the display console (if the sensor is too close, it may not be received by the display console).
Page 6
Figure 1 Fold out the desk stand, remove the battery cover, and insert three AAA (alkaline or lithium, avoid rechargeable) batteries in the back of the display console. All of the LCD segments will light up for a few seconds (to verify all segments are operating properly).
Do not touch any buttons until the remote sensor has reported in, or the radio search icon is no longer on, otherwise the remote sensor search mode will be terminated. When the remote sensor temperature has been received, the console will automatically switch to the normal mode, and all further settings can be performed.
3.2 Sensor Operation Verification Verify the indoor and outdoor temperature match closely with the console and sensor array in the same location (about 5 to 10' apart). The sensors should be within 2°F (the accuracy is ± 1°F). Allow about 30 minutes for both sensors to stabilize.
Page 9
. 12 hr/24 hr time format. Press the [+] key to switch between 12 and 24 hour format. Press the SET key to advance to the next setting. 2. Hour. Press the [+] or [-] key to increase or decrease the hour. Press the SET key to advance to the next setting.
7. Max/Min Clearing. The Max/Min can be programmed to clear daily (at midnight) or manually. Press the [+] key to switch between “Clears Daily” and Clears Manually. Press the SET key to exit setting. 4.2.2 Viewing the High and Low Alarms The high and low alarms can be set for Channels 1 and 2 only.
Press the CH/+ button to increase the HIGH alarm and the MIN/MAX button to decrease the HIGH alarm. Press and hold the + or - button to change rapidly. While the alarm value is flashing, press and hold the SET button for three seconds to toggle the alarm on and the alarm off.
4.4 Channel Selection Press the CH/+ button to switch the display between remote sensors 1 through 8, and scroll mode . In scroll mode, all of detected outdoor sensors will be displayed in five second intervals. 4.5 Sensor Search Mode If any of the sensor communication is lost, dashes (--.-) will be displayed on the screen.
following best practices for trouble free wireless communication. 1. Electro-Magnetic Interference (EMI). Keep the console several feet away from computer monitors and TVs. 2. Radio Frequency Interference (RFI). If you have other 433 MHz devices and communication is intermittent, try turning off these other devices for troubleshooting purposes.
The purpose of calibration is to fine tune or correct for any sensor error associated with the devices margin of error. The measurement can be adjusted from the console to calibrate to a known source. Calibration is only useful if you have a known calibrated source you can compare it against, and is optional.
increase (or decrease) the temperature reading, press and hold the CH/+ or MIN/MAX button. To return the temperature to the actual or uncalibrated measurement, press the SET button. Once the displayed temperature equals the calibrated source, press and hold the SET button for three seconds, or wait 15 seconds for timeout, and the temperature value will stop flashing.
Discussion: Temperature errors can occur when a sensor is placed too close to a heat source (such as a building structure, the ground or trees). To calibrate temperature, we recommend a mercury or red spirit (fluid) thermometer. Bi-metal (dial) and other digital thermometers are not a good source and have their own margin of error.
6. Specifications .1 Wireless Specifications Line of sight wireless transmission (in open air): 300 ● feet, 100 feet under most conditions. Frequency: 433 MHz ● Update Rate: 60 seconds ● 6.2 Measurement Specifications The following table provides specifications for the measured parameters.
Page 18
(M-F 8am to 4pm Arizona Time) 3. Technical Support: 480-283-1644 (M-F 8am to 4pm Arizona Time) Solution Problem If any of the sensor communication is lost, Wireless dashes (--.-) will be displayed on the screen. remote To reacquire the signal, press and hold the (thermometer) CHANNEL/+ button for 3 seconds, and the not reporting...
Page 19
Solution Problem Move the display console around electrical noise generating devices, such as computers, TVs and other wireless transmitters or receivers. Move the remote sensor to a higher location. Move the remote sensor to a closer location. Te m p e r a t u r e Make sure the thermometer is mounted in sensor reads a shaded area on the north facing wall.
8. Accessories The following software and hardware accessories are available for this weather station at www.AmbientWeather.com Accessory Description Ambient Weather F007PF Add additional remote Wireless Water thermometers. Supports up to Thermometer for WS14 eight remote sensors. Weather Stations Ambient Weather WS14...
9. Liability Disclaimer Please help in the preservation of the environment and return used batteries to an authorized depot. The electrical and electronic wastes contain hazardous substances. Disposal of electronic waste in wild country and/or in unauthorized grounds strongly damages the environment.
10. FCC Statement Statement according to FCC part 15.19: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference receive including interference that may cause undesired operation.
Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and ● receiver. Connect the equipment into an outlet on a circuit ● different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV ●...
Page 24
from the performance of repairs or alterations by someone other than an authorized Ambient, LLC authorized service center; (4) units used for other than home use (5) applications and uses that this product was not intended (6) the products inability to receive a signal due to any source of interference or metal obstructions and (7) extreme acts of nature, such as lightning strikes or floods.
