Evaporative Air Cooler
Instruction manual
Model: CM14EC-A
Thank you for your purchase. Please read the instructions carefully
before operating the unit and be sure to abide by the contents stated in
the instruction manual. Please keep this manual for future reference.
Contents
I. Functions........................2
II. Main Technical
Parameters.........................3
III. Electrical Schematic
Diagram............................3
IV. Product Diagram............4
............
VI. Cleaning and
Maintenance........................6
VIII. Troubleshooting and
..................
Maintenance
...
...5
8
