Oscilloscope Function

Horizontal
Sample Rate
Record Length
Sample / Division
Modes
Accuracy
Sweep Rate
Vertical
Bandwidth
Resolution
Channels
Coupling
Input impedance
Accuracy
Max. Input Volts
Volts / Division
Triggering
Type
Coupling
Slope
Internal Trigger
Sensitivity
Waveform Memory
Waveform Memory
25 MS/s (Dual CH mode)
50 MS/s (Single CH mode)
512 single shot mode
256 in all modes
25
Single shot, Roll, Normal
0.01%
1uS to 5S in 1, 2, 5 sequence
5MHz
8 Bit
Dual
AC, DC
1 MΩ
3%
DC or AC 600Vrms
50 mV to 500V in 1, 2, 5 sequence
CHA, CHB, External
AC, DC
Rising (↑) or Falling (↓) edge
2 / 20 Division
16 Screen shots
