Sensorid?
Setpt
Setpt?
Setpt%
Setptpct
Setptpct?
Span
Span?
Sparity
Sparity?
Srqmask
Srqmask?
Sstop
Sstop?
Stable?
Stabledelay
Stabledelay?
Stabletime
Stabletime?
StableWin
StableWin?
Standby
Standby?
Step
Operating Instructions - CPC8000
<sp><sensor#><sp>ID<sp>M
ENSOR,<sp><model>,<sp><
SN>,<sp>V<version><cr><lf>
value inside upper and lower
limits
<sp>+n.nnnnnE+nn<cr><lf>
Value in % of current range
Value in % of current range
<sp>+n.nnnnnE+nn<cr><lf>
desired pressure or ?
<sp>+n.nnnnnE+nn<cr><lf>
Even, ODD, NONE
<sp>CCCC<cr><lf>
Stable,Error or both
<sp>{string}<cr><lf>
1 or 2
<sp>X<cr><lf>
0 to 65535
<sp>XXXXXXX<cr><lf>
0 to 65535
<sp>+n.nnnnnE+nn<cr><lf>
%fs value
<sp>+n.nnnnnE+nn<cr><lf>
None
<sp>(YES or NO)<cr><lf>
value inside upper and lower
limits and inside the range of
the active sensor
High-End Pressure Controller
Returns the active sensor's serial number
and frmware version.
Sets the control setpoint for the instrument.
Returns the control setpoint in current units.
Sets the control setpoint in % of current
range.
Sets the control setpoint in % of current
range.
Returns the current setpoint in % of current
range.
Sets span on active transducer or for ?,
clears previous value, must be > 50% FS
and has a 1% limit. CALDISABLE must be
OFF/NO.
Returns span scale factor for active trans-
ducer.
Sets the serial parity.
Returns the serial parity.
Sets the CPC8000 to issue a service
request (SRQ) over the IEEE when the
pressure control is stable, or an error
occurs. These are 80 hex and 40 hex
respectively.
Returns "stable", "error" or "error, stable"
depending on the SRQ.
Sets the serial stop bits.
Returns the serial stop bits.
Returns Yes if instrument is stable, or No.
Sets the stable time to the number of
seconds specifed.
Returns the stable time.
Sets the stable time to the number of
seconds specifed.
Returns the stable time.
Sets the stable window as a %FS.
Returns the stable window.
Instrument placed in Standby mode
Returns yes if instrument is in Standby, no if
otherwise
Sets the control step size for the instrument
