mensor CPC8000 Operating Instructions Manual page 90

High-End Pressure Controller
CPC8000
Ptype?
RangeMax?
RangeMin?
Rate?
Rdecpt?
Reference
Reference?
Release?
Resolution
Resolution?
Rflter
Rflter?
Rsetpt
Rsetpt?
Runits
Runits?
Save_cal
Save_linearity
Sbaud
Sbaud?
Sdata
Sdata?
Sensor
Sensor?
90
<sp>CCCCC<cr><lf>
<sp>+n.nnnnnE+nn<cr><lf>
<sp>+n.nnnnnE+nn<cr><lf>
<sp>+n.nnnnnE+nn<cr><lf>
<sp>n<cr><lf>
{EXTVAC or ATM}
<sp>{EXTVAC or
ATM}<cr><lf>
15 char string.
Ex: Release? Test_stand_1
Returns: <sp>(YES or NO),
CCC...CCC<cr><lf>
<n>
<sp>n<cr><lf>
Value in %
<sp>+n.nnnnnE+nn<cr><lf>
Value in current units
<sp>+n.nnnnnE+nn<cr><lf>
Sec, min
<sp>XXXX<cr><lf>
9600, 19200, 38400, 57600,
115200
<sp>XXXX<cr><lf>
7 or 8
<sp>n<cr><lf>
1, 2, 3, or PRIMARY,
SECONDARY, TERTIARY
<sp>XXXXXXX,1<cr><lf>
Returns "Absolute" or "Gauge" for the
pressure type
Returns the maximum range of the active
transducer in the current units.
Returns the minimum range of the active
transducer in the current units.
Returns the rate reading of the instrument in
current units/current time unit.
See: Runits.
Returns the number of rate decimal points.
See: Resolution
Not used, kept for backwards compatibility.
Not used, kept for backwards compatibility.
This command is used to release control
of the instrument in a multiple computer
environment.
Yes if release is successful
No if instrument is being controlled with
another computer
CCC... = name of controlling computer or
AVAILABLE
See: Acquire? and Unlock
Sets the number of signifcant digits.
See: decpt
Returns the number of signifcant digits.
See: decpt
Sets the % of the rate flter.
Returns the rate flter.
Sets the rate setpoint.
Returns the rate setpoint.
Sets the rate time unit.
Returns the rate time unit.
Save calibration values.
Save linearity values.
Sets the serial baud rate.
Returns the serial baud data.
Sets the serial data bits.
Returns the serial data bits number.
Sets the active sensor.
Returns active sensor in long string format.
Operating Instructions - CPC8000
