TEAC
TEAC
NOTES
NOTES
PC board shown are viewed from parts side.
The parts with no reference number or no parts number
in the exploded views are not supplied.
As regards the resistors and capacitors, refer to the
circuit diagrams contained in this manual.
!
Parts marked with this sign are safety critical
components. they must be replaced with identical
components - refer to the appropriate parts list and
ensure exact replacement.
TEAC
EX-M1
CD Receiver System
CONTENTS
CONTENTS
2
3
4
6
10
16
18
Advertisement
Related Manuals for Teac EX-M1
Summary of Contents for Teac EX-M1
-
Page 1: Table Of Contents
TEAC TEAC TEAC EX-M1 CD Receiver System NOTES NOTES CONTENTS CONTENTS 1 SAFETY INFORMATION PC board shown are viewed from parts side. The parts with no reference number or no parts number 2 SPECIFICATIONS in the exploded views are not supplied. -
Page 2: Safety Information
EX-M1 1 SAFETY INFORMATION SAFETY INFORMATION This product has been designed and manufactured according to FDA regulations " title 21, CFR, chapter 1,subchapter J,based on the Radiation Control for Health and Safety Act of 1968" and is classified as class 1 laser product. There is not hazardous invisible laser radiation during operation because invisible laser radiation emitted inside of this product is completely confined in the protective housings. -
Page 3: Specifications
EX-M1 2 SPECIFICATIONS CD PLAYER Section Pickup: 3-beam pick-up Wavelength : 790 nm 20 Hz ~ 22 kHz Audio frequency response : CASSETTE DECK Section 4 track, 2 channel stereo Track System: 4.76 cm/sec Tape Speed: 0.4% or less Wow and Flutter:... -
Page 4: Adjustment And Checks
1. Set the function switch to the AM position. 2. Connect the test loop antenna across the output of the signal generator. 3. Connect the oscilloscope to the speaker terminal. 4. Set the signal generator as listed in the alignment chart. EX-M1 TUNER PCB... - Page 5 EX-M1 3-1-3 FM/AM alignment chart SG SETTING TUNER SETTING ADJUSTMENT POINT ADJUSTMENT ITEM 87.5MHz 87.5MHz Adjust for max.output. 1. FM band 1kHz, +/-22.5kHz dev. 90MHz 90MHz 1kHz, +/-22.5kHz dev. Adjust for max. output 106MHz and best waveform. 106MHz 1kHz, +/-22.5kHz dev.
-
Page 6: Exploded View And Parts List
EX-M1 4 EXPLODED VIEWS AND PARTS LIST EXPLODED VIEW - 1... -
Page 7: Exploded View
EX-M1 EXPLODED VIEW-1 REF. NO DESCRIPTION REMARKS PARTS NO. 01-EXM100030-00 CD PCB ASSY 56-07EXM1780-10 PCB BRACKET 01-EXM100007-00 POWER PCB ASSY 01-EXM100002-00 TUNER PCB ASSY 01-EXM100023-00 O/C SWITCH PCB ASSY 56-04EXM10A1-B0 FRONT CABINET 61-61DCD2000-00 LOCK WASHER 61-11DV60000-00 PCB BRACKET 01-EXM100009-00 H/P PCB ASSY... - Page 8 EX-M1 EXPLODED VIEW - 2...
- Page 9 EX-M1 EXPLODED VIEW-2 REF. NO PARTS NO. DESCRIPTION REMARKS 56-14EXM10A1-10 CD DOOR 56-58EXM1180-10 BADGE LOGO - TEAC 56-57EXM1110-70 CD DOOR LENS 56-57EXM1200-70 POWER LENS 56-57EXM1300-70 DISPLAY LENS 57-26EXM1000-00 FILTER SHEET 56-57EXM1400-70 BACK LIGHT LENS 56-07EXM1090-10 BACK LIGHT LENS BRACKET 01-EXM100016-00...
-
Page 10: Pc Boards And Parts Lists
EX-M1 5 PC BOARDS AND PARTS LIST TUNER PCB ASSY REMARKS REF. NO PARTS NO. DESCRIPTION 01-EXM100002-00 TUNER BOARD ASSY 48-EXM100002-00 TUNER PCB 32-211801100-00 FERRITE BAR 10X80MM CON2 43-9A2001071-00 WAFER 7 PINS 180C 31-210705100-20 CER.FILTER LT10.7MA5-A 31-245003015-20 CER.FILTER LTP450B CT1,2... - Page 11 EX-M1 TUNER PCB R/P PCB...
- Page 12 EX-M1 CD PCB ASSY REF. NO PARTS NO. DESCRIPTION REMARKS 01-EXM100030-00 CD BOARD ASSY 48-EXM100030-02 CD PCB 43-9A1501061-00 WAFER 6PIN P=1.5MM CON305 43-9B2001051-00 WAFER 5PIN P=2MM CON410 43-9B1001161-00 WAFER 16P P=1MM CON413 43-9A1001301-00 WAFER 30P P=1MM D403,404, 15-0001N4148-00 DIODE 1N4148...
- Page 13 EX-M1 CD PCB C414 CN401 D423 Q410 CON413 D422 J428 D403 R418 R419 R417 CON406 D408 D409 R420 Q404 D411 D410 R444 IC401 D413 D412 R125 Q402 C402 R415 D415 D414 R427 R416 CN402 D416 D407 R428 Q405 X402 Q409...
- Page 14 EX-M1 POWER PCB ASSY REF. NO PARTS NO. DESCRIPTION REMARKS POWER PCB ASSY 01-EXM100007-00 48-EXM100007-11 POWER PCB C745,746 26-351030300-00 CE-25V 1000UF CE-25V 3300UF C757 26-353330300-00 CON701 43-9A2001071-00 WAFER 7PIN P=2MM CON702,704 WAFER 5PIN P=2MM 43-9A2001051-00 CON703 43-9A2001091-00 WAFER 9PIN P=2MM...
- Page 15 EX-M1 POWER PCB FUSE DISPLAY PCB KEY PCB CON1 POWER OP/CL CON501 TIMER PL/PA TUNER TAPE MO/ST STOP REPEAT TIME LCD401 CN502 MEMORY CN503 LED401...
-
Page 16: Wiring Diagram
EX-M1 6 WIRING DIAGRAM TO DISPLAY PCB CON1 TO KEY PCB CON503 CD PCB CN401 CON413 TO KEY PCB CON501 CON406 CN402 TO KEY PCB CON502 TO TUNER PCB CON1 TO TUNER PCB CON2 TO CD DECK CON403 CON404 TO POWER PCB CON702... - Page 17 EX-M1 TO CASS DECK POWER PCB TO TUNER PCB CON3 TO CASS DECK TO CASS DECK TO TRANSFORMER TO H/P PCB...
-
Page 18: Included Accessories
EX-M1 6 INCLUDED ACCESSORIES INCLUDED ACCESSORIES REF. NO PARTS NO. DESCRIPTION REMARKS 77-14D120000-01 WARRANTY CARD 77-20EXM1000-00 INSTRUCTION BOOK 01-EXM10000-00 REMOTE CONTROL... - Page 19 TEAC NEDERLAND BV Oeverkruid 15,NL-4941 W Raamsdonksveer, Nederland Phone:0162-510210 TEAC BELGIUM NV/SA. c/o TEAC NEDERLAND BV, Oeverkruid 15, NL-4941 W Raamsdonksveer, Nederland Phone:+31-162-510860 TEAC ITALIANA S.p.A. Via C, Cantu 11, 20092 Cinisello Balsamo, Milano, Italy Phone:02-66010550 TEAC AUSTRALIA PTY., LTD.
- Page 20 4.5x3.5T SVC201 4.5x4.5T D33 SVC321 A049 YELLOW SVC321 450B LT10.7MA5-A 4.5MHz BLACK EX-M1 CD Receiver System...
- Page 21 POWER SECTION 2SB772P H.P PCB EX-M1 CD Receiver System...
- Page 22 CD SECTION LED2 LED1 BLUE BLUE LED PCB EX-M1 O/C SWITCH PCB CD Receiver System...
- Page 23 MCU SECTION CON501 CON503 47UF CON502 EX-M1 CD Receiver System...
- Page 24 CD RECEIVER SYSTEM LEVEL PARTS NO. DESCRIPTION Q'TY REF NO. 9A09682910 CD PCB ASSY 1 1-1 9A07392500 TR,9014C 2 Q401, Q402 9A07392500 TR,9014C 3 Q405- Q407 9A07392500 TR,9014C 1 Q412 9A07392600 TRANSISTOR 9015C 2 Q301, Q302 9A07392600 TRANSISTOR 9015C 2 Q403, Q404 9A07392600 TRANSISTOR 9015C 2 Q410, Q411 9A07392800 ZENER DIODE 5.6V 1/2W...
- Page 25 9A09695300 WAFER 2 PIN P=2MM 1 CON70 6 9A09695400 WAFER 4 PIN P=2.5MM 1 CON70 7 9A09695500 WAFER 5 PIN P=2.5MM 1 CON70 8 9A09695600 GLASS FUSE 3.5A 250V 1 FUSE 9A09695700 IC,BA5417 1 IC704 9A09695800 IC,LC75342 1 IC703 9A09695900 TR,2SB772P 1 Q723 9A09696000 TR,8550C 1 Q719...
- Page 26 6 1-36 125 1 9A09686400 SELF-TPG SCREW TA/BH 3X12 5 1-37 126 1 9A09686500 CD DOOR 1 2-1 127 1 9A09686600 BADGE LOGO-TEAC 1 2-2 128 1 9A09686700 CD DOOR LENS 1 2-3 129 1 9A09686800 POWER LENS 1 2-4...
- Page 27 150 1 9A09688300 MTG-BRACKET CASS KNOB 1 2-19 151 1 9A09688400 CASS KNOB-6KEY 1 2-20 152 1 9A09688500 F/CASS DECK 1 2-21 153 1 9A09688600 RECORDING PLATE 1 2-22 154 1 9A09688800 REC.PCB BRACKET 1 2-23 155 1 9A09688910 R/P PCB ASSY 1 2-24 9A07392500 TR,9014C 1 Q5...
- Page 28 MFR. OEM PARTS NO. ARTS 01-EXM100030-00 ARTS 11-9014C0001-00 ARTS 11-9014C0001-00 ARTS 11-9014C0001-00 ARTS 11-9015C0001-00 ARTS 11-9015C0001-00 ARTS 11-9015C0001-00 ARTS 12-156103100-00 ARTS 15-0001N4148-00 ARTS 15-0001N4148-00 ARTS 15-0001N4148-00 ARTS 15-0001N4148-00 ARTS 15-0001N4148-00 ARTS 38-310000000-30 ARTS 48-EXM100030-02 ARTS 43-9A1501061-00 ARTS 43-9B2001051-00 ARTS 43-9B1001161-00 ARTS 43-9A1001301-00 ARTS...
- Page 29 ARTS 43-9A2001021-00 ARTS 43-9A2501041-00 ARTS 43-9A2501051-00 ARTS 46-235420100-01 ARTS 16-BA5417000-01 ARTS 16-LC7534200-00 ARTS 11-2SB772000-00 ARTS 11-8550C0002-00 ARTS 11-8550C0002-00 ARTS 11-KSD882Y02-01 ARTS 12-110203100-02 ARTS 12-182103100-00 ARTS 01-EXM100002-00 ARTS 11-9014C0001-00 ARTS 11-9014C0001-00 ARTS 12-156103100-00 ARTS 15-SVC201SPA-11 ARTS 15-SVC321SPA-11 ARTS 15-0001N4148-00 ARTS 28-120110100-02 ARTS 32-211801100-00 ARTS...
- Page 30 ARTS 48-EXM100005-01 ARTS 41-151100000-0V ARTS 43-9B2001071-00 ARTS 43-9B2001040-00 ARTS 43-9B2001031-00 ARTS 17-57138V400-02 ARTS 56-07EXM1180-10 ARTS 58-261230001-00 ARTS 56-57EXM1520-40 ARTS 58-44NSX2000-00 ARTS 56-760000000-JA ARTS 56-24EXM1380-10 ARTS 58-04NSX2000-00 ARTS 56-24EXM1180-10 ARTS 56-24EXM1280-10 ARTS 56-24EXM1080-10 ARTS 56-24EXM1480-10 ARTS 68-013010057-00 ARTS 68-023008042-00 ARTS 68-013210107-00 ARTS 66-220300431-00 ARTS...
- Page 31 ARTS 61-11EXM1001-00 ARTS 56-55EXM10A1-10 ARTS 71-06EXM1000-20 ARTS 61-76SCD6600-00 ARTS 61-11EXM1000-00 ARTS 01-EXM100020-00 ARTS 11-9014C0001-00 ARTS 11-9015C0001-00 ARTS 43-9A2001041-00 ARTS 40-621000100-08 ARTS 48-EXM100020-00 ARTS 16-BA3308000-02 ARTS 41-191100100-03 ARTS 41-132212809-0V ARTS 58-01EXM1000-00 ARTS 56-06EXM11A1-A0 ARTS 61-250066000-00 ARTS 61-26SX88000-00 ARTS 61-260066000-00 ARTS 56-05EXM10A1-B0 ARTS 57-083225001-07 ARTS...
