AIRTRONICS SD-10G Operating Manual
Aircraft helicopter sailplane 2.4ghz fhss-3 digital proportional system
Hide thumbs
Also See for SD-10G:
- Operating manual (212 pages) ,
- Setup manual (41 pages) ,
- Manual (16 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for AIRTRONICS SD-10G
Summary of Contents for AIRTRONICS SD-10G
- Page 1 Page 1...
- Page 2 CONTENTS PACKAGING The packaging of your Airtronics SD-10G 2.4GHz FHSS-3 radio control system has been specially designed for the safe transportation and storage of the radio control system's components. After unpacking your radio control system, do not discard the packaging materials.
-
Page 3: Additional Receiver Information
In designing the SD-10G 2.4GHz FHSS-3 radio control system, our engineers listened to input from our test-pilots and radio control system. The SD-10G 2.4GHz FHSS-3 radio control system has been designed for the utmost in comfort and precise questions you might have regarding your SD-10G 2.4GHz FHSS-3 radio control system. -
Page 4: Safety And Usage Precautions
safety and usage precautions SAFETY moisture. 'Safety First' for yourself, for others, and for your equipment. receiver and servos by placing them operate your radio control equipment. If at any time during the operation of your model should strongly recommend you seek the assistance of experienced you feel or observe erratic operation or abnormality, end modelers or your local hobby shop for guidance. -
Page 5: Receiver Precautions
The foam should not be appropriate measures could result in damage to the receiver. When installing the The manufacturer disclaims all responsibility for damages resulting from use of components other than genuine Airtronics components. AMA INFORMATION dangerous manner. -
Page 6: Features And Specifications
FEATURES AND SPECIFICATIONS GENERAL FEATURES Full-Range 92104 10-Channel 2.4GHz FHSS-3 Receiver Transmitter Battery 10-Channel Programmable Fail Safe Adjustable Battery Fail Safe Voltage Trainer System Easy-to-Read LCD Display Servo Reversing, Centering, EPA, and Limits Custom Channel Assignments Stop Watch, Rhythm, System, and Integral Timers 3-Axis Triple Rates and Triple Expo Data Copy, Reset, and Transfer 2 Programmable Side Levers... -
Page 7: Transmitter And Receiver Specifications
FEATURES AND SPECIFICATIONS TRANSMITTER AND RECEIVER SPECIFICATIONS Transmitter Receiver SERVO SPECIFICATIONS - AVAILABLE SEPARATELY dealer for more information and availability. 94091Z Super Micro Servo 94761Z Micro Digital High-Torque High-Speed Ball Bearing Servo (23.1 x 11.1 x 22.0mm) (26.9 x 11.9 x 29.9mm) 94322Z Precision Heavy Duty Ball Bearing Standard Servo 94780M Digital High-Torque Metal Gear Ball Bearing Servo (39.1 x 20.0 x 36.0mm) -
Page 8: Features Familiarization
features familiarization TRANSMITTER CONTROL FEATURES DIAGRAMS these features can be found on page XX. FRONT Antenna Retractable Left-Hand Auxiliary Antenna (60mm) Push-Button Auxiliary Lever (VR6) Indicators Left-Hand Auxiliary Push-Button Auxiliary Dial Knob (VR7) Right-Hand Display Key LCD Display Charging Jack Programming Keys BACK arrays), auxiliary levers and auxiliary push-... -
Page 9: Features Descriptions
features familiarization RECEIVER FEATURES DIAGRAMS Coaxial Cables Bind LED All receiver channel assignments can be programmed to suit the user. For example, Antenna Reception be programmed to control Aileron or control Wires Bind Key RECEIVER CHANNEL SLOT AERO GLIDER HELI Channel Slot 1 Elevator Elevator... -
Page 10: Servo Connectors
features familiarization Charging Jack: battery, see page XX. transmitter. Coaxial Cables: Antenna Reception Wires. The Coaxial Cables can be bent DIN Connector: Direct Model Select Keys: Display Key: Activates the transmitter's hold the DISPLAY Key for ~ 2 seconds. To turn the DISPLAY Key once. -
Page 11: Transmitter Alarms
transmitter alarms ALARM DISPLAY AERO GLIDER HELI ALWAYS ACTIVE ALWAYS ACTIVE ALWAYS ACTIVE Throttle High Warning Alarm ALWAYS ACTIVE ALWAYS ACTIVE ALWAYS ACTIVE AUDIO LOW VOLTAGE ALARM THROTTLE HIGH WARNING ALARM FLIGHT MODE WARNING ALARM TRAINER MODE WARNING ALARM POWER SWITCH WARNING ALARM Page 11... -
Page 12: Custom Transmitter Adjustments
custom transmitter ADJUSTMENTS Every effort has been made to engineer the optimum 2.4GHz radio control system. For example, the transmitter control sticks are ball bearing-supported for smooth control and use springs that result in superior feel for most pilots. Some aspects of the transmitter are customizable though, to suit the user's particular taste. -
Page 13: Expansion Memory
6) Some helicopter pilots prefer to eliminate the throttle ratchet These long battery pins should be carefully slid through the matching holes in the back half of the transmitter before pushing covered by Airtronics, Inc. TRANSMITTER MODE ADJUSTMENTS CONTROL STICK... -
Page 14: Charging The Transmitter Battery
PLUGGING IN THE TRANSMITTER BATTERY When you receive your SD-10G 2.4GHz FHSS-3 radio control system, the transmitter battery may be from the battery into the matching slot in the transmitter case. The battery connector is polarized and SAFETY PRECAUTIONS AND CHARGING WARNINGS... -
Page 15: Airborne System Connections
airborne system connections 10-Channel receiver. 4.8v - 6.0v Receiver Battery Charge Plug Receiver Servos 4.8v - 6.0v a Y-Harness must be used to plug the servo into if a battery is also used in that slot. USING A RECEIVER LI-PO BATTERY An after-market use a Li-Po battery of desired capacity. -
Page 16: Lcd Display And Programming Keys
LCD display and programming keys The SD-10G 2.4GHz FHSS-3 Key, all used in conjunction to facilitate programming. This section summarizes the functions of these features in addition to detailing the main areas of the LCD Display. PROGRAMMING KEYS OVERVIEW The Display Key activates the transmitter's press and hold the DISPLAY Key for ~ 2 seconds. -
Page 17: Lcd Display Overview
LCD display and programming keys LCD DISPLAY OVERVIEW Status Status Trainer Status Voltage Trim 3 Trim 1 Trim 4 Trim 2 Trim 6 Active Flight Mode: Custom Menu Selection: Displays the Custom menu. The Custom menu is used to access your most-used programming options. Flight Mode Menu Selection: modes. -
Page 18: Transmitter And Receiver Binding
transmitter and receiver binding transmitter and receiver to prevent interference from radio controllers operated by other users. This operation is referred to as ' transmitter and transmitter from controlling a model that it's not currently programmed for. IMPORTANT 1) Turn the see page XX. -
Page 19: Mounting The Receiver
mounting the receiver When mounting the receiver in your model, it's important to mount the receiver exactly as described. In addition, the receiver poor reception, or in some cases, complete loss of reception. We recommend that you bind the transmitter and receiver prior to mounting the receiver into your model. WARNING Receiver Receiver... - Page 20 (low power mode) IMPORTANT 1) Turn the movement again. If there is still a problem, DO NOT FLY previously. POWER MODE TRANSMITTER STATUS WARNING still fails the Range Check, DO NOT FLY. Please contact Airtronics Customer Service. Page 20...
-
Page 21: Failsafe
fail safe transmitter and the Fail Safe function can be set to Hold the Custom servo positions can be set independently for all 10 channels. IMPORTANT the transmitter and the Preprogrammed Fail Safe Settings 1) Turn the displayed. to move the cursor to the right column. aileron Fail Safe position. - Page 22 fail safe Custom Fail Safe Settings 1) Turn the Fail Safe activates. the same procedures to set the preprogrammed aileron Fail Safe position. to move the cursor to the right column. 6) Repeat the same procedures to set the preprogrammed Fail Safe positions for the desired remaining channels. After setting same direction the control stick is moved.
