Summary of Contents for AIRTRONICS SD-10G
- Page 1 Email: service@airtronics.net Website: www.airtronics.net | Phone: (714) 963-0329...
- Page 2 This Aero Fixed Wing Quick Setup Guide contains information that we recommend using to set up your new model. Following each section in the order presented will allow you to quickly and easily set up your new model for use with your SD-10G transmitter.
- Page 3 If your model features two servos per aileron, each pair of aileron servos should be Y-Harnessed together, then AILERON>2 chosen. The SD-10G does not support more than 2 aileron channels in AERO mode. Choose the desired Flap Type Option Two Flap Type options are available - either 1 or 2.
- Page 4 Inner engines or motors should be Y-Harnessed together, then THROTTLE>2 chosen. The SD-10G does not support more than 2 throttle channels in AERO mode. 4) After making your Model Type selection choices, press the ENTER key.
- Page 5 The Model Name can consist of up to 8 letters, numbers, or symbols. Choose from capital letters, lower case letters, numbers, and various symbols. For more detailed information about using the Model Name function, see the following section in your SD-10G User’s Guide: Model Naming ...................Page 30 To name your model, follow the steps below: 1) With the transmitter turned ‘ON’, navigate to the SYSTEM>MODEL NAME menu.
- Page 6 Receiver Mounting For more detailed information about mounting the receiver into your model and routing the antenna wires, see the following section in your SD-10G User’s Guide: Mounting the Receiver ..............Page 24 Prior to mounting the receiver into your model, please read and understand the suggestions and warnings below: If mounting inside a carbon fiber fuselage, the antenna reception wires must be run outside of the model as described in the last notation below.
- Page 7 For detailed information about using the SURFACE menu, including how to change the various SURFACE menu options and how they affect your model, see the following section in your SD-10G User’s Guide: Surface Menu .................Pages 63 ~ 66...
- Page 8 Airtronics is Distributed Exclusively in North America by: Global Hobby Distributors 18480 Bandilier Circle Fountain Valley, CA 92708 Telephone: (714) 963-0329 Fax: (714) 964-6236 Email: service@airtronics.net http://globalservices.globalhobby.com http://www.airtronics.net Features and Specifications are Subject to Change Without Notice. All contents © 2011 Airtronics, Inc.
