built-in directional antennas which are optimized for vertical mounted orientation of the AP-367
access point.
Table 4 Applicable Mounting Kits for 360 Series
Part Number
AP-270-MNT-V1
AP-270-MNT-V2
AP-270-MNT-H1
AP-270-MNT-H2
The 360 Series access point does not ship with any mounting kits. These mounting kits are available as
accessories and must be ordered separately.
For installation instructions on AP-270-MNT-V1, AP-270-MNT-V2, AP-270-MNT-H1 and AP-270-MNT-H2, please
refer to the AP-270-MNT-V1 Installation Guide, AP-270-MNT-V2 Installation Guide, AP-270-MNT-H1 Installation
Guide and AP-270-MNT-H2 Installation Guide respectively.
Grounding the AP
The grounding must be completed before powering up the access point. The grounding wire should
be #8 AWG.
1. Peel the cover of one end of the grounding wire and place the bare grounding wire into the
included copper lug, and press firmly with the crimping pliers.
2. Fasten the copper lug to the grounding hole on the AP with the included M4 x6 screw.

Connecting the Ethernet Cable

To connect the Ethernet cable to the access point, perform the following steps using the cable gland
that ships with your access point.
Failure to use the included Ethernet cable gland can lead to connectivity and POE issues.
WARNING
The cable is not included and must be purchased separately. Purchase a suitable UV-resistant, outdoor rated,
CAT 5E or better RJ45 cable for use with the access point.
6
Description
Long mount kit for wall and vertical pole
mounting, 300 mm from vertical mounting
asset.
Short mount kit for wall and vertical pole
mounting, 75 mm from vertical mounting asset.
Hanging mount kit for hanging from inclined or
horizontal structure.
Flush mount kit for wall and ceiling mounting.
Applicable for
AP-365?
Yes
Yes
Yes
Yes
Aruba 360 Series Outdoor Access Points
Applicable for
AP-367?
No
No
Yes
Yes
