Bensons for Beds Opus Assembly Instructions Manual

Opus bed / 135cm & 150cm

Advertisement

Quick Links

P. O. Number:
Please Keep This Number For
Future Reference
THIS FORMS PARTS OF
YOUR GUARANTEE!!
Attention
Two Person Assembly
Needed
Regrettably self-assembly items cannot be returned once assembly is part or fully completed
unless the items are found to be faulty. Should you need to return the unassembled product,
please repack in its original packaging.
Important Information
l
We suggest spending a short time reading through this leaflet and then follow the simple
step-by-step instructions.
l
Carefully check that you have all the parts before beginning assembly.
l
Keep fittings out of children's reach and keep children well away from construction area.
l
We suggest retainning these instructions for future reference.
Product Information
l
This product Made Using Ash Timber And Ash Veneers in a natural finish.
Posture slats.
This product Conforms to BS1725
Care Instructions
l
Avoid exposing the furniture to excessive heat or direct sunlight as this can cause cracking and
deterioration of the color.
l
Periodically check & re-tighten all fasteners.
l
Periodically dust lightly with a clean soft cloth.
l
Do not use silicone based furniture polish.
l
Any spills should be removed immediately with a damp cloth.
l
TAKE CARE WHEN MOVING THE FURNITURE AND NEVER DRAG THE PIECES ACROSS
THE FLOOR, AS THIS WILL CAUSE DAMAGE TO THE JOINTS.
Opus bed / 135cm & 150cm
Assembly Instructions
Please keep these instructions for future reference.
page 1 of 8

Advertisement

loading
Need help?

Need help?

Do you have a question about the Opus and is the answer not in the manual?

Questions and answers

Summary of Contents for Bensons for Beds Opus

  • Page 1 P. O. Number: Please Keep This Number For Future Reference THIS FORMS PARTS OF YOUR GUARANTEE!! Opus bed / 135cm & 150cm Assembly Instructions Please keep these instructions for future reference. Attention Two Person Assembly Needed Regrettably self-assembly items cannot be returned once assembly is part or fully completed unless the items are found to be faulty.
  • Page 2 & Double size / 135cm x 190cm King size/150cm x 200cm Component of Carton A Component of Carton D (1) Headboard x 1 (9) Support leg x 2 (10) Posture slat x30/32 Component of Carton B (double in 30pcs; king in 32pcs) (2) Footboard x 1 (11) Footend drawer divider x 1 (3) Footboard drawer front (L &...
  • Page 4: Hardware List

    Hardware List (D) Ø8X40mm Dowel (A) M8X80mm Bolt (B) Washer (C) Spring washer x 16 (G) Slat holder x 15/16 (E) Ø10X40mm Dowel (F) Ø6X40mm Dowel (H) Slat holder x 30/32 (double in 15pcs; king in 16pcs) (double in 30pcs; king in 32pcs) x 32 (K) Ø7X50mm Screw (I) M5 Allen key...
  • Page 5 Step Attach Cross Bar (12) as shown. Attach Footend drawer D ivider (11) as shown ensuring the indicator arrows are pointing upwards and towards the foot end. Step 3 Attach The Foot End to the side rails and foot end drawer divider.Move the frame towards the head end for assembly as shown.
  • Page 6 Step Attach centre support Legs to Centre support rail Step 5 Carfully place centre rail & legs inside the frame attach using screws as shown. adjust the screw foot in the bottom of the leg in cases of uneven floor page 6 of 8...
  • Page 7 Step 6 Attach end caps to slats join with centre cap. insert end caps into both side rails firmly pushing down then push centre cap into centre rail. Step 7 Assemble Drawers as shown. In cases where the base grove is slightly out of alignment.
  • Page 8 Step 8 When inseting the drawer into the runners for the first time Please move the drawer back and forward a few times So to make sure that the ball bearings start to run smoothly Please press down under runner if you need take drawer off Please lift up under runner if you need take drawer off...
