Bensons for Beds Alexis Assembly Instructions Manual

Bensons for Beds Alexis Assembly Instructions Manual

135cm & 150cm bed with gas lift and storage

Advertisement

Quick Links

P.O Number :
Please Keep This Number For
Future Reference
THIS FORMS PARTS OF
YOUR GUARANTEE !!!
90 MIN
Regrettably self-assembly items cannot be returned once assembly is part or fully completed
unless the items are found to be faulty. Should you need to return the unassembled product,
please repack in its original packaging.
Important information
We suggest you spend a short time reading through this leaflet and then follow the simple
step-by-step instructions.
Carefully check that you have all the parts before beginning assembly.
Keep fittings out of children's reach and keep children well away from construction area.
We suggest you retain these instructions for future reference.
Product information
This product finished in Texture Black and Antique Copper.
Posture slats are made of bent plywood.
This is an upholstered product with plastic legs. The bed conforms to BS EN1725 & BSEN 5852 (FR).

Care instructions

Avoid exposing the furniture to excessive heat or direct sunlight as this can cause cracking and
deterioration of the color.
Periodically check & re-tighten any fastener .
Periodically dust lightly with a clean soft cloth.
Do not use silicone based furniture polish.
Any spills should be removed immediately with a damp cloth.
TAKE CARE WHEN MOVING THE FURNITURE AND NEVER DRAG THE PIECES ACROSS
THE FLOOR,AS THIS WILL CAUSE DAMAGE TO THE JOINTS
Alexis 135CM & 150CM Bed with Gas Lift and Storage
Assembly instructions
Please keep these instructions for future reference.
Page 1 of 19
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Alexis and is the answer not in the manual?

Questions and answers

Summary of Contents for Bensons for Beds Alexis

  • Page 1 Please Keep This Number For Future Reference THIS FORMS PARTS OF YOUR GUARANTEE !!! Alexis 135CM & 150CM Bed with Gas Lift and Storage Assembly instructions Please keep these instructions for future reference. 90 MIN Regrettably self-assembly items cannot be returned once assembly is part or fully completed unless the items are found to be faulty.
  • Page 2 Components of Carton A Headboard x 1 Cross Rail x 1 Base Boards x 2 Components of Carton B Footboard x 1 Left Side Panel x 1 Mattress Support x 2 Right Side Panel x 1 Page 2 of 19...
  • Page 3 Components of Carton B Corner Bracket x 4 Leg x 4 Back Tube x 1 Front Tube x 1 Centre Rail x 1 Wooden Slats Å Double - size x 30 pcs Å king - size x 32 pcs Side Rail x 2 Support Rail x 1 Bottom Centre Support Rail x 4...
  • Page 4 Components of Carton B Right Hinge x 1 Left Hinge x 1 Gas Lift x 2 Strap x 1 buckle x 1 buckle x 1 Short Support Leg x 1 Bed Frame Support Bar x 2 Base Support x 2 Left Bracket x 1 Right Bracket x 1 Single Slat Cap...
  • Page 5 Hardware List M6 x 15MM x 10 M6 x 20MM x 60 M6 x 35MM x 8 M6 x 40MM x 2 M6 x 4 M8 x 4 M6 x 8 M8 x 65MM x 4 ALLEN KEY 4MM x 1 WRENCH x 1 M8 x 57MM x 4 Step 1...
  • Page 6 Step 2 Å Attach base support and buckle Footboard .Using 20mm bolt and allen as shown. Å Screw onto Do not completely tighten the bolts, leave half of the bolt exposed. M6X20mm Page 6 of 19 I X1...
  • Page 7 Step 3 Å Attach Right bracket to right side panel and Left bracket to left side panel Using 20mm bolt and allen key as shown. M6X20mm Page 7 of 19 I X1...
  • Page 8 Step 4 Do not tighten the bolts fully until step 6. Step 5 Å Attach corner bracket to leg Using 57mm bolt and allen key as shown. M8X57mm Page 8 of 19 I X1...
  • Page 9 Step 6 Å 2 3 4 Attach corner bracket with leg Using 20mm bolt and allen key as shown. M6X20mm I X1 BX16 Step 7 Å Attach bottom centre rail Using 20mm bolt and allen key as shown. M6X20mm Page 9 of 19 I X1...
  • Page 10 Step 8 Å Attach support rail Using 15mm bolt and allen key as shown. M6X15mm I X1 Step 9 Å Attach support rail Using 15mm bolt and allen key as shown. Å Attach short support leg Using 40mm bolt and allen key as shown.
  • Page 11 Step 10 Å Gently place base boards inside the assembled bed base. Step 11 Å Attach bed frame support bar Using 65mm bolt and allen key as shown. M8X65mm Page 11 of 19 I X1...
  • Page 12 Step 12 Å Attach gas lift to right hinge Using M8 nut and wrench as shown. Incorrect: The orientation of part is upside down. J X1 Step 13 Å Attach gas lift to left hinge Using M8 nut and wrench as shown.
  • Page 13 Step 14 Å Attach Using 20mm bolt ,M6 Washer and allen key as shown. M6X20mm I X1 Step 15 Page 13 of 19...
  • Page 14 Step 16 Step 17 Å Attach centre rail Using 20mm bolt and allen key as shown. Å Attach side rail Using 35mm bolt , M6 Nut allen key , wrench as shown. M6X20mm M6X35mm Page 14 of 19 C X4 F X 4 I X1 J X1...
  • Page 15 Step 18 Å Attach cross rail Using 20mm bolt and allen key as shown. M6X20mm I X1 Step 19 Å Attach cross rail Using 40mm bolt and allen key as shown. M6X40mm Page 15 of 19 I X1...
  • Page 16 Step 20 Å Attach hinge Using 20mm bolt and allen key as shown. Å Attach Strap Strap installation steps M6X20mm Page 16 of 19 I X1...
  • Page 17 Step 21 Å Close base and attach safety buckle Step 22 Å Attach mattress support Using 20mm bolt and allen key as shown. M6X20mm Page 17 of 19 I X1...
  • Page 18 Step 23 Å 23.1 Insert wooden slats into single slat Cap 23.2 Press single slat Cap into side rail , repeat the same procedure for the opposite side. 23.3 Insert ends of both wooden slats into double slat cap ,then press double slat into Centre Rail as illustrated.
  • Page 19 ---WARNING: PLEASE DO NOT ALLOW CHILDREN OR PETS INSIDE THE STORAGE AREA. ---WARNING: PLEASE BE CAREFUL WHEN LIFTING. ONLY LIFT WITH MATTRESS ON TOP. TO BE OPERATED BY ADULTS ONLY. ---WARNING: PLEASE DO NOT PRESS DOWN ON THE MATTRESS WHEN THE BED FRAME IS IN THE LIFT UP POSITION.
