Read this manual carefully before operating this vehicle.
q
OWNER'S MANUAL
MT09TRA
2PP-28199-E3

Advertisement

Table of Contents
loading

Related Manuals for Yamaha TRACER MT09TRA

Summary of Contents for Yamaha TRACER MT09TRA

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MT09TRA 2PP-28199-E3...
  • Page 2 EAU70071 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Product: IMMOBILIZER Model: 1RC-00 Supplied by...
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the MT09TRA, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.

  • Page 4: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 MT09TRA OWNER’S MANUAL ©2016 by Yamaha Motor Co., Ltd. 1st edition, August 2016 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Safety information ......1-1 Handlebar position ...... 3-33 Checking the spark plugs .... 6-10 Adjusting the front fork ....3-33 Canister ........6-11 Description ........2-1 Adjusting the shock absorber Engine oil and oil filter cartridge... 6-11 Left view .........
  • Page 7 Table of contents Index ..........10-1 Checking and lubricating the brake and clutch levers ..... 6-28 Checking and lubricating the centerstand and sidestand ..6-29 Lubricating the swingarm pivots ... 6-30 Checking the front fork ....6-30 Checking the steering....6-31 Checking the wheel bearings ..

  • Page 8: Safety Information

    Safety information EAU1028B Take a training course. Beginners • Use extra caution when you are should receive training from a cer- approaching passing tified instructor. Contact an autho- through intersections, since in- Be a Responsible Owner rized motorcycle dealer to find out tersections are the most likely As the vehicle’s owner, you are respon- about the training courses nearest...
  • Page 9 Safety information tice riding your motorcycle with both hands and keep both control levers, footrests, or wheels where there is no traffic until you feet on the passenger footrests. and cause injury or an accident.  have become thoroughly famil- Never carry a passenger unless Always wear protective clothing iar with the motorcycle and all of...
  • Page 10 Yamaha accessories, which are avail- to minimize imbalance or instabili- of the motorcycle is changed. To avoid able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved ...
  • Page 11 Yamaha, even if sold and limit suspension travel, steering not recommended.  installed by a Yamaha dealer.
  • Page 12 Safety information  Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks.  Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.

  • Page 13: Description

    Description EAU10411 Left view 4,5,6 1. Front fork spring preload adjusting bolt (page 3-33) 8. Owner’s tool kit (page 6-2) 2. Shock absorber assembly rebound damping force adjusting screw 9. Seat lock (page 3-28) (page 3-35) 10.Shock absorber assembly spring preload adjusting ring (page 3-35) 3.

  • Page 14: Right View

    Description EAU10421 Right view 5 6,7 1. Rear brake fluid reservoir (page 6-23) 9. Coolant reservoir (page 6-14) 2. Fuel tank cap (page 3-24) 10.Engine oil level check window (page 6-11) 3. Front fork rebound damping force adjusting screw (page 3-33) 11.Engine oil filler cap (page 6-11) 4.

  • Page 15: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 3-20) 9. Main switch/steering lock (page 3-2) 2. Left handlebar switches (page 3-18) 3. Auxiliary DC jack (page 3-39) 4. Multi-function meter unit (page 3-6) 5. Front brake fluid reservoir (page 6-23) 6.

  • Page 16: Instrument And Control Functions

    Do not place any key close to  a Yamaha dealer to have them re-reg- magnets (this includes, but not istered. Do not use the key with the red limited to, products such as bow for driving.

  • Page 17: Main Switch/Steering Lock

    Instrument and control functions ference. EAU10474 cense plate light and auxiliary lights Main switch/steering lock come on, and the engine can be start- ed. The key cannot be removed. The headlights come on automatically when the engine is started and stay on until the key is turned to “OFF”, even if the engine stalls.
  • Page 18 Instrument and control functions may cause the battery to discharge. To lock the steering To unlock the steering 1. Push. 1. Push. 2. Turn. 2. Turn. 1. Turn the handlebars all the way to From the “LOCK” position, push the the left.

  • Page 19: Indicator Lights And Warning Lights

    9. Immobilizer system indicator light “ ” confirming that the oil level is correct or if the warning light remains on, have (see page 6-11), have a Yamaha deal- EAU11032 a Yamaha dealer check the vehicle. Turn signal indicator lights “...
  • Page 20 The ABS may not work correctly. If any When the traction control system is 1. Traction control system indicator light of the above occurs, have a Yamaha turned off, this indicator light will come “ ”...

  • Page 21: Multi-Function Meter Unit

    4. If one or both of the standard keys  speedometer do not start the engine, take the  tachometer vehicle and all 3 keys to a Yamaha  clock dealer to have the standard keys...
  • Page 22 Instrument and control functions  fuel meter  eco indicator To switch between kilometers and  transmission gear display miles, see page 3-12.  drive mode display  TCS display Tachometer  information display  setting mode display EWA12423 WARNING Be sure to stop the vehicle before making any setting changes to the 1.
  • Page 23 Instrument and control functions High-rpm zone: 11250 r/min and Fuel meter curs, have a Yamaha dealer check above the vehicle. Clock Eco indicator 1. Fuel meter The fuel meter indicates the amount of fuel in the fuel tank. The display seg- ments of the fuel meter disappear from 1.
  • Page 24 Instrument and control functions Drive mode display TCS display is appropriate for the vehicle speed. Transmission gear display GEAR A.TEMP °C C.TEMP °C TIME TRIP 0:00 1. Drive mode display 1. TCS display The drive mode display indicates which This display indicates which traction drive mode has been selected: “STD”, control system setting has been select- “A”...
  • Page 25 Instrument and control functions Information display and then push the “RESET” button again for two seconds. You can select which items are shown GEAR in each information display. See Set- TRIP-1 ting mode on page 3-12.  The odometer will lock at 999999. TRIP-2 ...
  • Page 26 Instrument and control functions formation. ant. The coolant temperature varies with changes in the weather and en- TRIP-F  Display–1  Display–2  gine load. Air temperature Display–3  TRIP-F If the message “Hi” flashes, stop the ve- A.TEMP ˚C hicle then stop the engine and let it cool.
  • Page 27 “km/L” or “L/100km”; or when be continuously displayed. Have a ECA15474 miles is selected “MPG” will be dis- NOTICE Yamaha dealer check the vehicle. played. If there is a malfunction, “– –.–” will  The “km/L” display shows the av- be continuously displayed.
  • Page 28 Instrument and control functions This mode allows you to set, select, or Resetting the maintenance counters This function allows you to check and reset the reset the items shown in the informa- 1. Use the select switch to highlight “TIME–2” and “TIME–3” tion display.
  • Page 29 Instrument and control functions 4. Push the menu switch to return to 2. Push the menu switch. The unit the setting mode menu. setting display will be shown. Time Trip Checking and resetting “TIME–2” and 0:07  When kilometers are already se- TIME-2 “TIME–3”...
  • Page 30 Instrument and control functions menu switch to confirm the selec- “ ”, and then push the menu the menu switch again. tion. switch to return to the setting mode menu. Display Unit Unit Display-1 Display-2 km or mile Display-3 km or mile km/L or L/100km km/L km/L or L/100km...
  • Page 31 Instrument and control functions Display-1 Display Brightness Display-1 Display-2 Display-3 C.TEMP TIME TRIP 5. When you are finished changing Adjusting the meter panel brightness Setting the clock the settings, use the select switch 1. Use the select switch to highlight 1.

  • Page 32: D-Mode (Drive Mode)

    Instrument and control functions 2. Push the menu switch. EAU47634 D-mode (drive mode) 3. Use the select switch to highlight Clock D-mode is an electronically controlled “YES”, and then push the menu engine performance system with three switch. mode selections (“STD”, “A”, and “B”). 5 55 Push the drive mode switch “MODE”...

  • Page 33: Handlebar Switches

    Instrument and control functions Right This mode allows the rider to enjoy EAU1234M Handlebar switches smooth and sporty drivability from the low-speed range to the high-speed Left range. Mode “A” Mode “A” offers a sportier engine re- sponse in the low- to mid-speed range compared to mode “STD”.
  • Page 34 Instrument and control functions vehicle is moving. lights, push the switch in after it has re- ECA10062 NOTICE turned to the center position. Using this switch changes the drive Do not use the hazard lights for an mode to “STD”, “A”, or “B” in the follow- extended length of time with the en- EAU12501 Horn switch “...

  • Page 35: Clutch Lever

    Instrument and control functions EAU12822 EAU12872 EAU26825 Clutch lever Shift pedal Brake lever The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip. 1. Clutch lever 1.

  • Page 36: Brake Pedal

    “ ” mark on the brake lever. EAU12944 EAU63040 Brake pedal The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- trol system, which acts on the front and rear brakes independently. Operate the brakes with ABS as you would conventional brakes.

  • Page 37: Traction Control System

    However, special tools are turns, when accelerating hard at a required, so please consult your sharp lean angle, or while braking, Yamaha dealer. and cannot prevent front wheel slip- ping. As with any motorcycle, ap- ECA20100 NOTICE...
  • Page 38 Instrument and control functions TCS “1” Setting the traction control system TCS “1” minimizes traction control sys- EWA15441 WARNING tem assist. Be sure to stop the vehicle before TCS “2” making any setting changes to the traction control system. Changing TCS “2”...

  • Page 39: Fuel Tank Cap

    “ ” indicator light and check the vehicle as soon as possible. the “ ” warning light will come on. 4. Have a Yamaha dealer check the vehicle and turn off the “ ” warn- ing light. 1. Unlock.

  • Page 40: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 not properly closed and locked.
  • Page 41 ECA11401 same identifier when fueling. NOTICE Use only unleaded gasoline. The use Your Yamaha engine has been de- of leaded gasoline will cause severe signed to use premium unleaded gaso- damage to internal engine parts, line with a research octane number of such as the valves and piston rings, 95 or higher.

  • Page 42: Fuel Tank Overflow Hose

    Instrument and control functions pairable damage to the catalytic EAU74230 EAU13434 Fuel tank overflow hose Catalytic converter converter. This model is equipped with a catalytic converter in the exhaust system. EWA10863 WARNING The exhaust system is hot after op- eration. To prevent a fire hazard or burns: Do not park the vehicle near ...

  • Page 43: Seats

    Instrument and control functions EAU65800 Seats Passenger seat To remove the passenger seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 1. Cap 2. Seat holder 2. Rider seat lock lever 2. Remove the key. To install the rider seat 1.

  • Page 44: Adjusting The Rider Seat Height

    Instrument and control functions EAU63050 Adjusting the rider seat height The rider seat height can be adjusted to one of two positions to suit the rider’s preference. The rider seat height was adjusted to the lower position at delivery. 1. Projection 1.
  • Page 45 Instrument and control functions the rider seat into seat holder B as shown. 1. Projection 1. Rider seat height position adjuster 2. “H” position slot 2. Projection 3. Grommet 1. Projection 6. Install the passenger seat. 2. Seat holder B (for high position) 4.

  • Page 46: Helmet Holder

    Instrument and control functions 5. Align the projection on the bottom EAU63060 3. Place the helmet on the right side Helmet holder of the rider seat with the “L” posi- of the vehicle, and then install the seat. WARNING! Never ride with The helmet holder is located under the tion slot, and then push the rear of passenger seat.

  • Page 47: Storage Compartment

    Instrument and control functions EAU62550 EAU63070 Storage compartment Windshield Make sure that the projection on the To suit the rider’s preference, the wind- slide plate holder fits into the corre- shield can be changed to one of three sponding hole in the slide plate. positions.

  • Page 48: Adjusting The Headlight Beams

    The headlight beam adjusting knobs Always adjust the spring preload on erence. Have a Yamaha dealer adjust are used to raise or lower the height of both fork legs equally, otherwise the position of the handlebar.
  • Page 49 Instrument and control functions Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 19.0 mm (0.75 in) 12 click(s) in direction (b)* Standard: Standard: Distance A = 16.0 mm (0.63 in) 7 click(s) in direction (b)* Maximum (hard): Maximum (hard): Distance A = 4.0 mm (0.16 in)

  • Page 50: Adjusting The Shock Absorber Assembly

    Instrument and control functions Rebound damping force EAU57940 Adjusting the shock absorber 3 2 1 To increase the rebound damping force 7 6 5 4 assembly and thereby harden the rebound damp- This shock absorber assembly is ing, turn the adjusting screw in direction equipped with a spring preload adjust- (a).

  • Page 51: Luggage Strap Holders

    EAU63080 Luggage strap holders sembly yourself. Take the shock To obtain a precise adjustment, it is ad- absorber assembly to a Yamaha visable to check the actual total number dealer for any service. of turns of the damping force adjusting mechanism.

  • Page 52: Sidestand

    Instrument and control functions Yamaha dealer repair it if it does not EAU15306 EAU54491 Sidestand Ignition circuit cut-off system function properly. The sidestand is located on the left side The ignition circuit cut-off system (com- of the frame. Raise the sidestand or...
  • Page 53 ”. stand during this inspection. • 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Push the “ ” side of the start/engine stop switch.

  • Page 54: Auxiliary Dc Jack

    Auxiliary DC jack Auxiliary DC connector EWA14361 This vehicle is equipped with an auxilia- WARNING ry DC connector. Consult your Yamaha To prevent electrical shock or dealer before installing any accesso- short-circuiting, make sure that the ries. cap is installed when the auxiliary DC jack is not being used.

  • Page 55: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 6-14 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 56 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 6-17, 6-27 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-27 •...
  • Page 57 For your safety – pre-operation checks ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-37 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 58: Operation And Important Riding Points

     a lean angle sensor to stop the en-  understand, ask your Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this EWA10272 position.

  • Page 59: Shifting

    The neutral indicator etc. light should come on. If not, ask a The gear positions are shown in the il- Yamaha dealer to check the elec- lustration. trical circuit. 3. Start the engine by sliding the To shift the transmission into the neu- switch toward “...

  • Page 60: Tips For Reducing Fuel Consumption

    Operation and important riding points ECA10261 EAU16811 EAU16842 Tips for reducing fuel Engine break-in NOTICE consumption There is never a more important period Even with the transmission in  in the life of your engine than the period the neutral position, do not Fuel consumption depends largely on between 0 and 1600 km (1000 mi).

  • Page 61: Parking

    Do not park on a slope or on soft  Yamaha dealer check the vehi- ground, otherwise the vehicle cle. may overturn, increasing the risk of a fuel leak and fire.

  • Page 62: Periodic Maintenance And Adjustment

    – possibly leading to any repair establishment or individual pending on the weather, terrain, geo- death. See page 1-2 for more in- that is certified (if applicable). Yamaha graphical location, and individual use, dealers are trained and equipped to formation about carbon monox- the maintenance intervals may need to perform these particular services.

  • Page 63: Owner's Tool Kit

    Periodic maintenance and adjustment EAU59910 a Yamaha dealer perform it for you. Owner’s tool kit 1. Owner’s tool kit The owner’s tool kit is located under the passenger seat. Some tools are also lo- cated on the bottom of the passenger seat.

  • Page 64: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU71051 Periodic maintenance chart for the emission control system...
  • Page 65 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check the air cut-off valve, reed Air induction valve, and hose for damage.

  • Page 66: General Maintenance And Lubrication Chart

    (24000 mi) • Perform dynamic inspection using Diagnostic system       Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 40000 km (24000 mi) • Check operation. Clutch ...
  • Page 67 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 1000 km (600 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
  • Page 68 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Rear suspension relay arm and 23 * ...
  • Page 69 Periodic maintenance and adjustment EAU72800  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 70: Removing And Installing The Panel

    Periodic maintenance and adjustment EAU18752 shown. Removing and installing the panel The panel shown needs to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the panel needs to be removed and installed. 1.

  • Page 71: Checking The Spark Plugs

    Do not attempt to diagnose such problems yourself. Instead, have Clean the surface of the spark plug a Yamaha dealer check the vehicle. gasket and its mating surface, and then If a spark plug shows signs of electrode wipe off any grime from the spark plug erosion and excessive carbon or other threads.

  • Page 72: Canister

    Periodic maintenance and adjustment EAU36112 EAU1987B Canister Engine oil and oil filter cartridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart.
  • Page 73 2. Oil filter cartridge Make sure that the O-ring is properly An oil filter wrench is available at a seated. Yamaha dealer. 1. Engine oil drain bolt 7. Install the new oil filter cartridge 2. Gasket 6. Apply a thin coat of clean engine...
  • Page 74 Tightening torque: ECA11621 correct, immediately turn the engine Oil filter cartridge: NOTICE off and have a Yamaha dealer check 17 N·m (1.7 kgf·m, 12 lb·ft) In order to prevent clutch slip-  the vehicle. page (since the engine oil also 8.

  • Page 75: Coolant

    The coolant should be between the corrosion. If water has been minimum and maximum level marks. added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as 6-14...
  • Page 76 Periodic maintenance and adjustment soon as possible, otherwise the effectiveness of the coolant will be reduced. [ECA10473] Coolant reservoir capacity (up to the maximum level mark): 0.25 L (0.26 US qt, 0.22 Imp.qt) EAU63111 To change the coolant 1. Place the vehicle on the center- 1.
  • Page 77 If Antifreeze/water mixture ratio: 9. Remove the coolant drain bolt and coolant is leaking, have a Yamaha its gasket to drain the cooling sys- dealer check the cooling system. Recommended antifreeze: tem.

  • Page 78: Air Filter Element

    Check the engine idling speed and, if Measure the throttle grip free play as maintenance and lubrication chart. necessary, have it corrected by a shown. Have a Yamaha dealer replace the air Yamaha dealer. filter element. Engine idling speed: 1100–1300 r/min 1.

  • Page 79: Valve Clearance

    Therefore, it tires): 1 person: must be adjusted by a Yamaha dealer is essential to maintain the tires in good Front: at the intervals specified in the periodic condition at all times and replace them 250 kPa (2.50 kgf/cm...
  • Page 80 Tires age, even if they have not been in” for it to develop its optimal cracked, have a Yamaha dealer re- used or have only been used occasion- characteristics. place the tire immediately.

  • Page 81: Cast Wheels

    If any avoid tire deflation during a ride. damage is found, have a Yamaha high speeds. dealer replace the wheel. Do not Brand-new tires can have a rela- ...

  • Page 82: Adjusting The Clutch Lever Free Play

    Measure the clutch lever free play as clutch does not operate correctly, have shown. a Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the 1.

  • Page 83: Brake Light Switches

    The front and rear brake pads must be come on just before braking takes ef- checked for wear at the intervals spec- fect. If necessary, have a Yamaha deal- ified in the periodic maintenance and er adjust the brake light switches.

  • Page 84: Checking The Brake Fluid Level

    Periodic maintenance and adjustment Rear brake touches the brake disc, have a Yamaha EAU40262 Checking the brake fluid level dealer replace the brake pads as a set. Before riding, check that the brake fluid is above the minimum level mark.

  • Page 85: Changing The Brake Fluid

    EAU22733 Changing the brake fluid age. Refill with the same type of Have a Yamaha dealer change the  brake fluid. Adding a brake fluid brake fluid at the intervals specified in other than DOT 4 may result in a the periodic maintenance and lubrica- harmful chemical reaction.

  • Page 86: Drive Chain Slack

    4. To tighten the drive chain, turn the To adjust the drive chain slack drive chain slack adjusting bolt on Consult a Yamaha dealer before ad- each side of the swingarm in direc- justing the drive chain slack. tion (a). To loosen the drive chain, 1.

  • Page 87: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment EAU23026 Cleaning and lubricating the drive chain The drive chain must be cleaned and lubricated at the intervals specified in the periodic maintenance and lubrica- tion chart, otherwise it will quickly wear out, especially when riding in dusty or wet areas.

  • Page 88: Checking And Lubricating The Cables

    Yamaha dealer at the intervals speci- ed if necessary. If a cable is damaged fied in the periodic maintenance chart.

  • Page 89: Checking And Lubricating The Index

    Periodic maintenance and adjustment Shift pedal EAU44276 EAU23144 Checking and lubricating the Checking and lubricating the brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu- ride, and the lever pivots should be lu-...

  • Page 90: Checking And Lubricating The Centerstand And Sidestand

    EWA10742 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 91: Lubricating The Swingarm Pivots

    Yamaha dealer check or re- tion. WARNING! To avoid injury, ed by a Yamaha dealer at the intervals pair it. securely support the vehicle so specified in the periodic maintenance there is no danger of it falling and lubrication chart.

  • Page 92: Checking The Steering

    If any free The battery is located under the rider hub or if the wheel does not turn play can be felt, have a Yamaha seat. (See page 3-28.) smoothly, have a Yamaha dealer check dealer check or repair the steering.
  • Page 93 To charge the battery once a month and fully charge it if Have a Yamaha dealer charge the bat- necessary. tery as soon as possible if it seems to 3. Fully charge the battery before in- stallation.

  • Page 94: Replacing The Fuses

    Periodic maintenance and adjustment EAU63131 Replacing the fuses The fuse boxes and individual fuses are located under the rider seat (See page 3-28.) and behind panel A (See page 6-9.). To access fuse box 1, the main fuse, and the fuel injection system fuse, re- move the rider seat.
  • Page 95 Periodic maintenance and adjustment age to the electrical system and Specified fuses: possibly a fire. Main fuse: [EWA15132] 50.0 A Auxiliary fuse 1: 2.0 A Auxiliary fuse 2: 2.0 A Terminal fuse 1: 2.0 A Terminal fuse 2: 2.0 A Headlight fuse: 1.

  • Page 96: Headlights

    4. If the fuse immediately blows If a headlight does not come on, check again, have a Yamaha dealer the fuses and then have a Yamaha check the electrical system. dealer check the vehicle. When the headlights are set to low beam, one headlight will come on.

  • Page 97: Brake/Tail Light

    1. Remove the turn signal light lens If the brake/tail light does not come on, by removing the screw. have a Yamaha dealer check it. 1. Turn signal light bulb 3. Insert a new bulb into the socket, push it in, and then turn it clock- wise until it stops.

  • Page 98: Replacing The License Plate Light Bulb

    3. Insert a new bulb into the socket. self. However, should your motorcycle 4. Install the socket (together with the require any repair, take it to a Yamaha bulb) by pushing it in, and then in- dealer, whose skilled technicians have...
  • Page 99 Periodic maintenance and adjustment heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 6-38...

  • Page 100: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 101 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 102: Motorcycle Care And Storage

    Be Cleaning ble. Rust and corrosion can develop sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE advice on what products to use be- used.
  • Page 103 After riding in the rain, near the sea or oughly with water. For additional clean- connectors, instruments, on salt-sprayed roads ing, use Yamaha Windshield Cleaner switches and lights), breather Since sea salt or salt sprayed on roads or another high-quality windshield hoses and vents.
  • Page 104 8. Let the motorcycle dry completely before storing or covering it. EWA11132  Consult a Yamaha dealer for ad- WARNING vice on what products to use. Contaminants on the brakes or tires  Washing, rainy weather or humid...

  • Page 105: Storage

    Motorcycle care and storage EAU26183 2. Fill up the fuel tank and add fuel spark plug caps. Storage stabilizer (if available) to prevent 4. Lubricate all control cables and the the fuel tank from rusting and the pivoting points of all levers and Short-term fuel from deteriorating.

  • Page 106: Specifications

    Specifications Dimensions: EAU69997 Compression ratio: Fuel reserve amount: 11.5 : 1 2.6 L (0.69 US gal, 0.57 Imp.gal) Overall length: Fuel injection: Starting system: 2160 mm (85.0 in) Electric starter Overall width: Throttle body: Lubrication system: 950 mm (37.4 in) ID mark: Wet sump Overall height:...
  • Page 107 Specifications 6th: Rear: Wheel travel: 1.037 (28/27) 290 kPa (2.90 kgf/cm , 42 psi) 137 mm (5.4 in) Chassis: Rear suspension: 2 persons: Front: Frame type: Type: 250 kPa (2.50 kgf/cm , 36 psi) Diamond Swingarm (link suspension) Rear: Caster angle: Spring: 24.0 ...
  • Page 108 Specifications License plate light: Signaling system fuse: 5.0 W 7.5 A Meter lighting: Ignition fuse: 15.0 A Neutral indicator light: Parking lighting fuse: 7.5 A High beam indicator light: Radiator fan motor fuse: 15.0 A Oil level warning light: Fuel injection system fuse: 20.0 A Turn signal indicator light: ABS control unit fuse:...

  • Page 109: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUM- 1. Vehicle identification number 1. Engine serial number...

  • Page 110: Diagnostic Connector

    This in-  Fuel-injection and emission-relat- formation will be needed when ordering ed data spare parts from a Yamaha dealer. Yamaha will not disclose this data to a third party except:  With the consent of the vehicle owner ...
  • Page 111 Index D-mode (drive mode) ......3-17 Drive chain, cleaning and lubricating ..6-26 ABS ............3-21 License plate light bulb, replacing..6-37 Drive chain slack ........6-25 ABS warning light ........3-4 Luggage strap holders ......3-36 Air filter element........6-17 Auxiliary DC connector ......3-39 Engine break-in ........5-3 Main switch/steering lock ......
  • Page 112 Index Storage ........... 7-4 Storage compartment ......3-32 Swingarm pivots, lubricating ....6-30 Throttle grip and cable, checking and lubricating ........6-27 Throttle grip free play, checking.... 6-17 Tires ............6-18 Tool kit ............ 6-2 Traction control system......3-22 Traction control system indicator light..3-5 Troubleshooting ........
  • Page 114 Original instructions PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2016.10-1.3×1 !
