  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MT09 MT09A B87-28199-E0 0...
  • Page 2 EAU70070 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Product: IMMOBILIZER Model: 1RC-00 Supplied by...
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MT09/MT09A. The Owner’s Man- ual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 MT09/MT09A OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, October 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Safety information ......1-1 Luggage strap holders ....3-29 Checking the throttle grip free Sidestand ........3-30 play..........6-15 Description ........2-1 Ignition circuit cut-off system..3-30 Valve clearance ......6-15 Left view .......... 2-1 Auxiliary DC connector....3-32 Tires..........
  • Page 7 Table of contents Battery ........... 6-29 Replacing the fuses ....... 6-31 Replacing the headlight bulb ..6-34 Replacing an auxiliary light bulb ..6-36 Brake/tail light ........ 6-37 Replacing a turn signal light bulb ..........6-38 Replacing the license plate light bulb ..........

  • Page 8: Safety Information

    Safety information EAU1028B Take a training course. Beginners • Use extra caution when you are should receive training from a cer- approaching passing tified instructor. Contact an autho- through intersections, since in- Be a Responsible Owner rized motorcycle dealer to find out tersections are the most likely As the vehicle’s owner, you are respon- about the training courses nearest...
  • Page 9 Safety information tice riding your motorcycle with both hands and keep both control levers, footrests, or wheels where there is no traffic until you feet on the passenger footrests. and cause injury or an accident.  have become thoroughly famil- Never carry a passenger unless Always wear protective clothing iar with the motorcycle and all of...
  • Page 10 Yamaha accessories, which are avail- ble on both sides of the motorcycle of the motorcycle is changed. To avoid able only from a Yamaha dealer, have to minimize imbalance or instabili- the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or by Yamaha for use on your vehicle.
  • Page 11 Yamaha, even if sold and limit suspension travel, steering not recommended.  installed by a Yamaha dealer.
  • Page 12 Safety information  Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks.  Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.

  • Page 13: Description

    Description EAU10411 Left view 3 4,5,6 11 10 1. Front fork spring preload adjusting bolt (page 3-26) 8. Shock absorber assembly spring preload adjusting ring (page 3-28) 2. Shock absorber assembly rebound damping force adjusting screw 9. Shift pedal (page 3-18) (page 3-28) 10.Engine oil drain bolt (page 6-9) 3.

  • Page 14: Right View

    Description EAU10421 Right view 1. Fuel tank cap (page 3-22) 9. Rear brake light switch (page 6-20) 2. Front fork rebound damping force adjusting screw (page 3-26) 10.Rear brake fluid reservoir (page 6-21) 3. Headlight (page 6-34) 4. Fuse box 1 (page 6-31) 5.

  • Page 15: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 3-18) 2. Left handlebar switches (page 3-16) 3. Main switch/steering lock (page 3-2) 4. Multi-function meter unit (page 3-7) 5. Front brake fluid reservoir (page 6-21) 6. Right handlebar switches (page 3-16) 7.

  • Page 16: Instrument And Control Functions

    Do not place any key close to  a Yamaha dealer to have them re-reg- magnets (this includes, but not istered. Do not use the key with the red limited to, products such as bow for driving.

  • Page 17: Main Switch/Steering Lock

    Instrument and control functions ference. EAU10474 cense plate light and auxiliary lights Main switch/steering lock come on, and the engine can be start- ed. The key cannot be removed. The headlight comes on automatically when the engine is started and stays on until the key is turned to “OFF”, even if the engine stalls.
  • Page 18 Instrument and control functions may cause the battery to discharge. To lock the steering To unlock the steering 1. Push. 1. Push. 2. Turn. 2. Turn. 1. Turn the handlebars all the way to From the “LOCK” position, push the the left.

  • Page 19: Indicator Lights And Warning Lights

    “ ” (for ABS models) (see page 6-9), have a Yamaha dealer If the warning light does not come on 9. Immobilizer system indicator light “ ”...
  • Page 20  The ABS may not work correctly. If any For radiator-fan-equipped vehi- MT09A of the above occurs, have a Yamaha cles, the radiator fan(s) automati- This warning light comes on if a prob- dealer check the system as soon as...
  • Page 21 “ON”. The light should come on for a lems in the immobilizer system circuits. vehicle and all 3 keys to a Yamaha few seconds, and then go off. (See page 3-14 for an explanation of...

  • Page 22: Multi-Function Meter Unit

    Instrument and control functions MT09 MT09A EAU73263 Multi-function meter unit 1. Transmission gear display 1. Transmission gear display 2. Tachometer 2. Tachometer 1. “SELECT” button 3. Drive mode display 3. Eco indicator “ECO” 2. “RESET” button 4. Fuel meter 4. TCS display 5.
  • Page 23 Instrument and control functions Speedometer multi-function meter unit The tachometer allows the rider to equipped with the following: monitor the engine speed and keep it  a speedometer within the ideal power range.  a tachometer When the key is turned to “ON”, the ta- ...
  • Page 24 When the last segment starts flashing (“ ” will also flash for MT09), refuel as soon as possible. If a problem is detected in the electrical ciruit, the fuel level segments and “ ”...
  • Page 25 “B”. For more details on the modes and Drive mode display on how to select them, see pages 3-15 and 3-17. MT09 Consider the following tips to reduce fuel consumption: TCS display (for equipped models)  Avoid high engine speeds during MT09A acceleration.
  • Page 26 Instrument and control functions Multi-function display  self-diagnosis mode (MT09) L/100 km” or “AVE_ _._ MPG”, coolant  a brightness control display temperature mode “C”, air intake tem- perature mode “Air_ _ C”, odometer mode “ODO”, and tripmeter modes ...
  • Page 27 Instrument and control functions  Air_ _ C  ODO  TRIP 1  TRIP Instantaneous fuel consumption fuel consumption display settings, push 2  F-TRIP mode the “SELECT” button for one second. For the UK: If traveling at speeds under 20 km/h (12 F-TRIP ...
  • Page 28 Instrument and control functions Coolant temperature mode Air intake temperature mode  “AVE_ _._ L/100 km”: The average amount of fuel necessary to travel 100 km is shown.  “AVE_ _._ MPG” (for the UK): The average distance that can be trav- eled on 1.0 Imp.gal of fuel is shown.
  • Page 29 “ON” and con- key and both standard keys to a cuits. tinue pushing the button until the Yamaha dealer and have the stan- If a problem is detected in the immobi- display switches to the brightness dard keys re-registered.

  • Page 30: D-Mode (Drive Mode)

    Instrument and control functions control mode. EAU47634 This mode allows the rider to enjoy D-mode (drive mode) 3. Push the “RESET” button to set smooth and sporty drivability from the D-mode is an electronically controlled the brightness level. low-speed range to the high-speed engine performance system with three 4.

  • Page 31: Handlebar Switches

    Instrument and control functions Left (MT09A) Right EAU1234K Handlebar switches Left (MT09) 1. Pass switch “ ” 1. Start/Engine stop switch “ ” 2. Dimmer switch “ ” 2. Drive mode switch “MODE” 3. Turn signal switch “ ” 3. Hazard switch “...
  • Page 32 Instrument and control functions EAU12461 of the traction control system and an emergency or to warn other drivers Turn signal switch “ ” the TCS settings. when your vehicle is stopped where it To signal a right-hand turn, push this might be a traffic hazard.

  • Page 33: Clutch Lever

    Instrument and control functions  The selected mode is shown on EAU12822 EAU12872 Clutch lever Shift pedal the drive mode display. (See page 3-10.) 1. Clutch lever 1. Shift pedal The clutch lever is located on the left The shift pedal is located on the left side of the handlebar.

  • Page 34: Brake Lever

    Instrument and control functions EAU26825 “ ” mark on the brake lever. EAU12944 Brake lever Brake pedal The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip.

  • Page 35: Abs (For Abs Models)

    ABS (for ABS models) ABS system.  The ABS performs a self-diagno- The Yamaha ABS (Anti-lock Brake sis test each time the vehicle first System) features a dual electronic con- starts off after the key is turned to trol system, which acts on the front and “ON”...

  • Page 36: Traction Control System (For Equipped Models)

    Instrument and control functions  EAU73141 notice slight changes in engine and ex- Traction control can be turned on Traction control system haust sounds when the system has en- or off only when the vehicle is (for equipped models) gaged. stopped.

  • Page 37: Fuel Tank Cap

    Yamaha dealer check the To close the fuel tank cap vehicle as soon as possible. 1. Push the fuel tank cap into position with the key inserted in the lock.

  • Page 38: Fuel

    Gasoline is poisonous and can hole. Stop filling when the fuel cause injury or death. Handle gaso- Your Yamaha engine has been de- reaches the bottom of the filler signed to use premium unleaded gaso- line with care. Never siphon gaso- tube.

  • Page 39: Fuel Tank Breather Hose And Overflow Hose

    Do not park the vehicle near  ohol containing methanol possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn. or vehicle performance problems. Park the vehicle in a place ...

  • Page 40: Seat

    Instrument and control functions pairable damage to the catalytic EAU57991 Seat converter. To remove the seat 1. Open the seat lock cover, insert the key into the seat lock, and then turn the key counterclockwise. 1. Projection 2. Seat holder 2.

  • Page 41: Storage Compartment

    (7 lb) for the storage com- suspension, turn the adjusting bolt on partment. each fork leg in direction (b). Do not exceed the maximum  load of 174 kg (384 lb) (MT09A) 177 kg (390 lb) (MT09) for the ve- 3-26...
  • Page 42 Instrument and control functions Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 19.0 mm (0.75 in) 11 click(s) in direction (b)* Standard: Standard: Distance A = 16.0 mm (0.63 in) 8 click(s) in direction (b)* Maximum (hard): Maximum (hard): Distance A = 4.0 mm (0.16 in)

  • Page 43: Adjusting The Shock Absorber Assembly

    Instrument and control functions Rebound damping force EAU57940 Adjusting the shock absorber 3 2 1 To increase the rebound damping force 7 6 5 4 assembly and thereby harden the rebound damp- This shock absorber assembly is ing, turn the adjusting screw in direction equipped with a spring preload adjust- (a).

  • Page 44: Luggage Strap Holders

    EAU15152 Luggage strap holders sembly yourself. Take the shock To obtain a precise adjustment, it is ad- absorber assembly to a Yamaha visable to check the actual total number dealer for any service. of turns of the damping force adjusting mechanism.

  • Page 45: Sidestand

    Instrument and control functions Yamaha dealer repair it if it does not EAU15306 EAU57950 Sidestand Ignition circuit cut-off system function properly. The sidestand is located on the left side The ignition circuit cut-off system (com- of the frame. Raise the sidestand or...
  • Page 46 Instrument and control functions WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the start/engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 47: Auxiliary Dc Connector

    Instrument and control functions EAU70640 Auxiliary DC connector This vehicle is equipped with an auxilia- ry DC connector. Consult your Yamaha dealer before installing any accesso- ries. 3-32...

  • Page 48: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 6-11 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 49 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 6-15, 6-26 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-25 •...
  • Page 50 For your safety – pre-operation checks ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-30 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 51: Operation And Important Riding Points

    If This model is equipped with: there is a control or function you do not  an engine auto-stop system. The understand, ask your Yamaha dealer. engine stops automatically if left EWA10272 idling for 20 minutes. If the engine WARNING...

  • Page 52: Starting The Engine

    The neutral indicator  Engine trouble warning light light should come on. If not, ask a  Immobilizer system indicator Yamaha dealer to check the elec- light trical circuit.  Traction control system indica- 3. Start the engine by pushing the tor light (for equipped models) “...

  • Page 53: Shifting

    Operation and important riding points EAU16673 ECA10261 4. At the recommended shift points Shifting NOTICE shown in the following table, close Even with the transmission in  the throttle, and at the same time, the neutral position, do not quickly pull the clutch lever in. coast for long periods of time 5.

  • Page 54: Tips For Reducing Fuel Consumption

    Operation and important riding points clutch lever in, use the brakes to EAU64150 EAU16811 Tips for reducing fuel Recommended shift points slow the motorcycle, and continue consumption The recommended shift points during to downshift as necessary. acceleration deceleration 4. Once the motorcycle has stopped, Fuel consumption depends largely on shown in the table below.

  • Page 55: Engine Break-In

    Do not park on a slope or on soft  During this period, prolonged full-throt- Yamaha dealer check the vehi- ground, otherwise the vehicle tle operation or any condition that might cle. may overturn, increasing the result in engine overheating must be risk of a fuel leak and fire.

  • Page 56: Periodic Maintenance And Adjustment

    – possibly leading to any repair establishment or individual pending on the weather, terrain, geo- death. See page 1-2 for more in- that is certified (if applicable). Yamaha graphical location, and individual use, dealers are trained and equipped to formation about carbon monox- the maintenance intervals may need to perform these particular services.

  • Page 57: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 58: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU46912 Periodic maintenance chart for the emission control system...

  • Page 59: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU1770M General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi)  1 * Air filter element •...
  • Page 60 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 800 km (500 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
  • Page 61 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Change.      ...
  • Page 62 Periodic maintenance and adjustment EAU18681  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 63: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. Tightening torque: If a spark plug shows signs of electrode Spark plug: erosion and excessive carbon or other 13 Nm (1.3 m·kgf, 9.4 ft·lbf)

  • Page 64: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment EAU1990A to collect the used oil. Engine oil and oil filter 4. Remove the engine oil filler cap, cartridge the engine oil drain bolt and its The engine oil level should be checked gasket to drain the oil from the before each ride.
  • Page 65 Make sure that the O-ring is properly 17 Nm (1.7 m·kgf, 12 ft·lbf) An oil filter wrench is available at a seated. Yamaha dealer. 8. Install the engine oil drain bolt and 7. Install the new oil filter cartridge its new gasket, and then tighten 6.

  • Page 66: Coolant

    ECA11621 correct, immediately turn the engine NOTICE off and have a Yamaha dealer check In order to prevent clutch slip-  the vehicle.  The coolant level must be checked...
  • Page 67 If water has been added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as soon as possible, otherwise the 6-12...
  • Page 68 Periodic maintenance and adjustment 7. Install the coolant reservoir and its cover by placing them in the origi- nal position, and then installing the collars and bolts. 8. Remove the coolant drain bolt and its gasket to drain the coolant from the cooling system.

  • Page 69: Air Filter Element

    If Antifreeze/water mixture ratio: maintenance and lubrication chart. coolant is leaking, have a Yamaha Have a Yamaha dealer replace the air dealer check the cooling system. Recommended antifreeze: filter element. High-quality ethylene glycol anti-...

  • Page 70: Checking The Engine Idling Speed

    To prevent this necessary, have it corrected by a shown. from occurring, the valve clearance Yamaha dealer. must be adjusted by a Yamaha dealer Engine idling speed: at the intervals specified in the periodic 1100–1300 r/min maintenance and lubrication chart.

  • Page 71: Tires

    174 kg (384 lb) (MT09A) the specified limit, if the tire has a nail or WARNING 177 kg (390 lb) (MT09) glass fragments in it, or if the sidewall is Operation of this vehicle with im- * Total weight of rider, passenger, car-...
  • Page 72 EWA10472 WARNING characteristics of the motorcy- cle may be different, which Have a Yamaha dealer replace  could lead to an accident. excessively worn tires. Besides Always make sure that the valve being illegal, operating the vehi- ...

  • Page 73: Cast Wheels

    Always adjust the tire air pres- er damage before each ride. If any  Manufacturer/model: BRIDGESTONE/S20R sure according to the operating damage is found, have a Yamaha DUNLOP/D214 conditions. dealer replace the wheel. Do not FRONT and REAR: attempt even the smallest repair to Tire air valve: the wheel.

  • Page 74: Adjusting The Clutch Lever Free Play

    Measure the clutch lever free play as clutch does not operate correctly, have shown. a Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the 1.

  • Page 75: Brake Light Switches

    The brake light, which is activated by the brake pedal and brake lever, should come on just before braking takes ef- fect. If necessary, have a Yamaha deal- er adjust the brake light switches. 1. Rear brake light switch 2. Rear brake light switch adjusting nut...

  • Page 76: Checking The Front And Rear Brake Pads

    Periodic maintenance and adjustment EAU22393 touches the brake disc, have a Yamaha EAU40262 Checking the front and rear Checking the brake fluid level dealer replace the brake pads as a set. brake pads Before riding, check that the brake fluid is above the minimum level mark.
  • Page 77 If the brake Use only the specified brake flu-  fluid level goes down suddenly, have a id; otherwise, the rubber seals Yamaha dealer check the cause before 6-22...

  • Page 78: Changing The Brake Fluid

    Periodic maintenance and adjustment EAU22733 EAU22762 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid at the intervals specified in checked before each ride and adjusted the periodic maintenance and lubrica- if necessary.
  • Page 79 Periodic maintenance and adjustment EAU57971 To adjust the drive chain slack Consult a Yamaha dealer before ad- justing the drive chain slack. 1. Loosen the axle nut and the lock- nut on each side of the swingarm. 1. Drive chain slack adjusting bolt 1.

  • Page 80: Cleaning And Lubricating The Drive Chain

    If a cable is damaged wet areas. Service the drive chain as or does not move smoothly, have a follows. Yamaha dealer check or replace it. WARNING! Damage to the outer ECA10584 NOTICE housing of cables may result in in-...

  • Page 81: Checking And Lubricating The Throttle Grip And Cable

    In addi- pedals should be checked before each tion, the cable should be lubricated by a ride, and the pedal pivots should be lu- Yamaha dealer at the intervals speci- bricated if necessary. fied in the periodic maintenance chart. Brake pedal The throttle cable is equipped with a rubber cover.

  • Page 82: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 83: Lubricating The Swingarm Pivots

    Yamaha dealer check or re- tion. WARNING! To avoid injury, ed by a Yamaha dealer at the intervals pair it. securely support the vehicle so specified in the periodic maintenance there is no danger of it falling and lubrication chart.

  • Page 84: Checking The Steering

    If any free (See page 3-25.) smoothly, have a Yamaha dealer check play can be felt, have a Yamaha This model is equipped with a VRLA the wheel bearings. dealer check or repair the steering.
  • Page 85 To charge the battery once a month and fully charge it if Have a Yamaha dealer charge the bat- necessary. tery as soon as possible if it seems to 3. Fully charge the battery before in- stallation.

  • Page 86: Replacing The Fuses

    1. Remove the bolt and quick fasten- ers. 2. Pull the right side panel off as 1. Fuse box 1 shown. MT09 1. Right side panel 2. Bolt 3. Quick fastener 1. Ignition fuse The quick fasteners are removed by 2.
  • Page 87 Periodic maintenance and adjustment MT09A MT09 The main fuse, the fuel injection system 1. Ignition fuse fuse, and fuse box 2 are located under 1. Radiator fan motor fuse 2. ABS control unit fuse 2. Backup fuse (for clock and immobilizer the seat.
  • Page 88 7.5 A possibly a fire. [EWA15132] 3. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. 4. If the fuse immediately blows again, have a Yamaha dealer 6-33...

  • Page 89: Replacing The Headlight Bulb

    Periodic maintenance and adjustment check the electrical system. EAU58001 Replacing the headlight bulb This model is equipped with a halogen bulb headlight. If the headlight bulb burns out, replace it as follows. ECA10651 NOTICE Take care not to damage the follow- ing parts: Headlight bulb ...
  • Page 90 Periodic maintenance and adjustment 1. Bolt 1. Grommet 1. Headlight coupler 2. Headlight unit side cover 4. Disconnect the auxiliary light cou- 6. Remove the headlight bulb cover. 2. Pull up the headlight unit cover to pler. separate it from the headlight unit. 1.

  • Page 91: Replacing An Auxiliary Light Bulb

    13. Install the grommets. and then connect the headlight 14. Place the headlight unit side cov- coupler. ers in their original position, and 1. Bolt then install the bolts. 15. Have a Yamaha dealer adjust the headlight beam if necessary. 6-36...

  • Page 92: Brake/Tail Light

    Brake/tail light This model is equipped with an LED-type brake/tail light. If the brake/tail light does not come on, have a Yamaha dealer check it. 1. Bolt 1. Auxiliary light bulb 2. Headlight unit side cover 4. Insert a new bulb into the socket.

  • Page 93: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment EAU24205 EAU58010 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the license plate light unit by removing the screw. by removing the nuts and collars, and then remove the license plate light bulb socket (together with the bulb) by pulling it out.

  • Page 94: Supporting The Motorcycle

    Supporting the motorcycle Front wheel (for non-ABS models) EWA14841 WARNING For the ABS model, have a Yamaha dealer remove and install the wheel. EAU56270 1. License plate light bulb To remove the front wheel 3. Insert a new bulb into the socket.
  • Page 95 Periodic maintenance and adjustment on the ground, and then put the sidestand down. 5. Tighten the wheel axle, the front wheel axle pinch bolt and the brake caliper bolts to the specified torques. Tightening torques: Wheel axle: 65 Nm (6.5 m·kgf, 47 ft·lbf) Front wheel axle pinch bolt: 1.

  • Page 96: Rear Wheel (For Non-Abs Models)

    Periodic maintenance and adjustment EAU44802 Rear wheel (for non-ABS models) EWA14841 WARNING For the ABS model, have a Yamaha dealer remove and install the wheel. EAU56701 1. Axle nut 1. Drive chain slack adjusting bolt 2. Locknut To remove the rear wheel 2.

  • Page 97: Troubleshooting

    2. Retainer for checking these vital systems your- self. However, should your motorcycle 2. Install the drive chain onto the rear require any repair, take it to a Yamaha 1. Wheel axle sprocket. dealer, whose skilled technicians have 3. Install the axle nut.
  • Page 98 Periodic maintenance and adjustment heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 6-43...

  • Page 99: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 100 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 101: Motorcycle Care And Storage

    Be Cleaning ble. Rust and corrosion can develop sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE advice on what products to use be- used.
  • Page 102 Motorcycle care and storage off any detergent residue using Test the product on a small hid- remain well into spring. plenty of water, as it is harmful den part of the windshield to 1. Clean the motorcycle with cold wa- to plastic parts.

  • Page 103: Storage

    EWA11132 WARNING  ECA10811 Consult a Yamaha dealer for ad- NOTICE Contaminants on the brakes or tires vice on what products to use. Storing the motorcycle in a  can cause loss of control.
  • Page 104 Motorcycle care and storage 2. Fill up the fuel tank and add fuel spark plug caps. stabilizer (if available) to prevent 4. Lubricate all control cables and the the fuel tank from rusting and the pivoting points of all levers and fuel from deteriorating.

  • Page 105: Specifications

    Primary reduction ratio: 2.40 L (2.54 US qt, 2.11 Imp.qt) Curb weight: 1.681 (79/47) With oil filter removal: 188 kg (414 lb) (MT09) Final drive: 2.70 L (2.85 US qt, 2.38 Imp.qt) 191 kg (421 lb) (MT09A) Chain Coolant quantity:...
  • Page 106 Voltage, capacity: Type: 174 kg (384 lb) (MT09A) 12 V, 8.6 Ah (10 HR) Hydraulic single disc brake Headlight: 177 kg (390 lb) (MT09) Specified brake fluid: * (Total weight of rider, passenger, cargo Bulb type: DOT 4 and accessories)
  • Page 107 Specifications Bulb wattage  quantity: Fuse(s): Headlight: Main fuse: H4, 60.0 W/55.0 W x 1 50.0 A Brake/tail light: Auxiliary fuse: 2.0 A Front turn signal light: Headlight fuse: 10.0 W  2 15.0 A Rear turn signal light: Signaling system fuse: 10.0 W ...

  • Page 108: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUM- 1. Vehicle identification number 1. Engine serial number...

  • Page 109: Diagnostic Connector (Mt09A)

    The model label is affixed to the frame under the seat. (See page 3-25.) Re- The diagnostic connector is located as cord the information on this label in the shown. space provided. This information will be needed when ordering spare parts from a Yamaha dealer.

  • Page 110: Index

    Index Maintenance, emission control system ..6-3 Matte color, caution........7-1 ABS (for ABS models) ......3-20 Engine break-in ......... 5-5 Model label..........9-2 ABS warning light (for ABS models) ..3-5 Engine idling speed, checking ....6-15 Multi-function meter unit......3-7 Air filter element ........6-14 Engine oil and oil filter cartridge ....
  • Page 111 Index Tool kit ............6-2 Traction control system ......3-21 Traction control system indicator light ..3-6 Traction control system switch ....3-17 Troubleshooting........6-42 Troubleshooting charts ......6-44 Turn signal indicator light......3-4 Turn signal light bulb, replacing....6-38 Turn signal switch........3-17 Valve clearance ........6-15 Vehicle identification number.....9-1 Wheel bearings, checking .......6-29 Wheel, front (for non-ABS models)..6-39 Wheel, rear (for non-ABS models) ..6-41...
  • Page 114 Original instructions PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2015.11-0.8×1 !
