RG-AP630(CD) Wireless Access Point Quick Installation Guide
Mark the locations of the four screw holes by using the marker. Drill four 8 mm diameter holes. Tap expansion anchors into
the holes, and drive screws through the mounting bracket into the anchors to fix the bracket.
Attach the tie rod to the mounting plate and fix the rod with the supplied M8x40 screws. Adjust the AP orientation, and
drive the two-side screws on the rod.

8 Connecting the Fiber Cable

Insert the SFP module into the SFP port, and then insert the fiber cable with a liquid-tight adapter into the module.
