- Page 1 RG-AP130-W Access Point Quick Installation Guide...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
-
Page 3: Obtaining Technical Assistance
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks Website: http://www.ruijienetworks.com/ Service Email: service_rj@ruijienetworks.com ... -
Page 4: Packing List
1.1 Packing List Table 1-1 Packing List Item Name Quantity Unit AP130-W Host AP130-W Plate Cover (White) Piece RG-AP130-W Access Point Quick Installation Guide Copy Product Warranty Copy Philips Flat Head Screw Piece Hex Socket Screw Piece 1.2 Product Image... - Page 5 Figure1-3 Bottom View of RG-AP130-W ① 1000M LAN port (RJ45) Note: Figure1-4 Side View of RG-AP130-W...
- Page 6 ⑤ Key hole ⑥ Locking bar hole device through the power adapter) The key hole and locking bar hole are used with security accessories. Figure1-5 Rear View of RG-AP130-W ② RJ45 pass through port Note ① 1000M PoE uplink port (RJ11 combo) The access point can be powered either with a DC power adapter or through Power over Ethernet (PoE).
- Page 7 Press for more than 3 Reset the system and restore the factory settings (namely, the seconds AP is operating in FIT mode). 1.4 Installing the RG-AP130-W Wireless Access Point Step 1: Remove the 86-type panel from the wall with a screwdriver. (If needed)
-
Page 8: Quick Configuration
Step 2: Connect the Ethernet cable to the UpLNK port on the rear of the access point, and connect the telephone cords to the pass through port if needed. Step 3: Align the screw holes on the panel with the screw holes in the wall, use screws to fasten the access point. Step 4: Attach the frameplate cover as shown in the figure. - Page 9 In the Fat mode, the IP address of the LAN port is 192.168.111.1/24, and the IP address of the UpLNK port is 192.168.110.1/24. Step 2: Log into the AP device. Enter the username and password, click Login. The default username is admin, and the default password is admin. Step 3: Perform quick configuration.
- Page 10 Click the button to perform quick configuration or to switch to the Fat mode. When the AP is switched to the Fat mode, the Quick Settings page is displayed The AP device can work in AP access mode or wireless routing mode. 1 ) Select AP Access Mode.
- Page 11 Configure the WiFi parameters, and click Finish to finish the configuration.
- Page 12 2 ) Select Wireless Routing Mode. Configure the Internet connection type and related parameters, then click Next. Configure the WiFi parameters, and click Finish to finish the configuration.
