- Page 1 RG-AP630 (CD) Wireless Access Point Quick Installation Guide...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance http://www.ruijienetworks.com/ Ruijie Networks Website: Service Email: service_rj@ruijienetworks.com http://www.ruijienetworks.com/service.aspx Technical Support: ...
-
Page 4: Packing List
M8x40 screw with spring and flat washers Piece Liquid-light adapter Piece Grounding cable Piece Hose clamp Piece Product Warranty Manual Copy RG-AP630 (CD) Wireless Access Point Quick Installation Copy Guide 2 Accessories 3 Product Appearance Product Appearance of RG-AP630 (CD) -
Page 5: Installation Tools
RG-AP630(CD) Wireless Access Point Quick Installation Guide Note: 1. Console port 3. 10/100/1000 Base-T auto-sensing Ethernet/PoE IN port 4. SFP combo port 4 Installation Tools The tool kit is customer supplied. - Page 6 RG-AP630(CD) Wireless Access Point Quick Installation Guide 5 LEDs State Meaning Blinking green Initialization in progress Solid yellow Initialization is complete, but no CAPWAP connection. System status Solid green Initialization is complete, and a CAPWAP connection is established. Solid red...
- Page 7 RG-AP630(CD) Wireless Access Point Quick Installation Guide Attach the mounting plate to the bottom of the AP and fasten the plate with the four M8x20 screws. Attach the tie rod to the mounting plate and fasten the rod with the M8x40 screws after AP is well-positioned, shown in the following figure.
-
Page 8: Connecting The Fiber Cable
RG-AP630(CD) Wireless Access Point Quick Installation Guide Mark the locations of the four screw holes by using the marker. Drill four 8 mm diameter holes. Tap expansion anchors into the holes, and drive screws through the mounting bracket into the anchors to fix the bracket. -
Page 9: Connecting The Network Cable
RG-AP630(CD) Wireless Access Point Quick Installation Guide Before insertion, make sure the nut of the liquid-tight adapter is in loose state. Tighten the liquid-tight adapter and the nut on the AP first, and then that of the liquid-tight adapter. 9 Connecting the Network Cable Thread the original network cable through the liquid-tight adapter. - Page 10 RG-AP630(CD) Wireless Access Point Quick Installation Guide 11 Installing the Security Lock (Optional) The security lock is user-supplied. The lock loop on the AP is for your security needs. You can fasten the AP to a fixture for anti-theft. First, fasten the cable...
