Dynojet POWER COMMANDER V Installation Instructions Manual page 4

FIG.D
FIG.E
FIG.F
19-008 www.powercommander.com
7 Route the white connectors from the PCV down the right hand side of the ATV
and plug them in-line of the stock TPS connector (Fig. D).
8 Use one of the supplied zip ties to hold the PCV harness to the frame.
9 Locate the stock #2 injector harness on the right hand side of the ATV.
This connector is located in the right wheel well of the ATV. This may be located
by following the wiring harness back from the injector until you find the connector
shown in Fig. E.
10 Unplug this connector.
11 Plug the YELLOW colored wires from the PCV in-line of the stock wiring
harness (Fig. F).
2009-2010 Polaris 800 PCV - 4
