5 Slide the T-bar ceiling mount bracket base into the back of the access point. The locking tab fits into
a groove in the outside of the AP.
Figure 6: Mounting the AP3915i to the T-bar
6 Hold the AP and rock it back and forth to ensure that it is securely mounted.
7 Attach the Ethernet cable's RJ45 connector to the LAN1/GE1 port and place the ceiling tile back in
place.

Connecting the Power Supply

You can connect the power supply to the AP using the PoE option or the optional 12V DC power supply.
1 Power is provided through the RJ45 Ethernet port (LAN1 port) of AP3915i. This is the preferred
method of powering the AP on ceiling and high wall installations.
2 The AP3915i can also be powered by an external DC power supply. It is plugged into an AC source.
Note
There is no wall mount option for the 12V DC power supply option.
